Azetidine Amino Acid Analysis: Advanced LC-MS Methods for Drug Discovery and Metabolite Profiling

Scarlett Patterson Jan 12, 2026 437

This comprehensive guide details the application of Liquid Chromatography-Mass Spectrometry (LC-MS) for the analysis of azetidine-containing amino acids and their derivatives.

Azetidine Amino Acid Analysis: Advanced LC-MS Methods for Drug Discovery and Metabolite Profiling

Abstract

This comprehensive guide details the application of Liquid Chromatography-Mass Spectrometry (LC-MS) for the analysis of azetidine-containing amino acids and their derivatives. Azetidines, strained four-membered nitrogen heterocycles, are emerging as critical pharmacophores in medicinal chemistry, prized for improving metabolic stability, conformational restriction, and target affinity in peptide-based therapeutics and proteolysis-targeting chimeras (PROTACs). The article systematically addresses four core analytical intents: establishing the foundational chemical and pharmacological significance of azetidine amino acids; detailing optimized LC-MS/MS methodologies for separation, detection, and quantification; troubleshooting common challenges related to ionization, chromatography, and sample preparation; and validating methods while comparing performance across different MS platforms (e.g., QqQ, Q-TOF, Orbitrap). Aimed at researchers and drug development scientists, this resource provides actionable protocols and insights to enable precise characterization of these valuable synthetic building blocks and their metabolites in complex biological matrices.

Azetidine Amino Acids 101: Chemical Properties, Pharmacological Significance, and Analytical Imperatives

Application Notes: LC-MS Analysis of Azetidine Amino Acid Products

Conformational Strain & Reactivity

The four-membered azetidine ring (C3H6NH) is characterized by significant angle strain (~20° deviation from ideal tetrahedral geometry) and torsional strain (Pitzer strain). This ring strain, estimated at approximately 25-27 kcal/mol, is a key driver of its unique reactivity compared to larger saturated nitrogen heterocycles like pyrrolidines (5-membered) and piperidines (6-membered). The constrained geometry forces substituents into eclipsed or near-eclipsed conformations, which influences both their chemical stability and biological activity profiles.

Quantitative Data on Azetidine Properties

Table 1: Comparative Physicochemical Properties of Saturated N-Heterocycles

Property Azetidine (4) Pyrrolidine (5) Piperidine (6)
Ring Strain (kcal/mol) 25-27 ~5 ~0
pKa of conjugate acid ~11.3 ~11.3 ~11.2
Dipole Moment (D) ~1.8 ~1.6 ~1.2
C-N-C Bond Angle ~86° ~108° ~111°
% Planarity of N High Moderate Low

Table 2: Impact of Azetidine Incorporation on Peptide Properties

Parameter α-Amino Acid (Control) 2-Azetidine Acid Analog 3-Azetidine Acid Analog
LogP Reduction (Avg.) - -0.4 to -0.6 -0.3 to -0.5
Metabolic Stability (t1/2, in vitro) Baseline +35-50% +20-40%
Caco-2 Permeability (Papp x10^-6 cm/s) Baseline -15% to +10% -20% to -5%
Conformational Freedom (ΔS) Baseline Significantly Reduced Reduced

Research Reagent Solutions Toolkit

Table 3: Essential Reagents & Materials for Azetidine Amino Acid Synthesis & Analysis

Item Function/Application
Fmoc-Azetidine-3-carboxylic Acid Building block for solid-phase peptide synthesis (SPPS).
Boc-Azetidine-2-carbonyl Methyl Ester Protected precursor for solution-phase coupling.
Pd/C or Pd(OH)2/C Catalyst for hydrogenolytic deprotection of CBz or benzyl groups on azetidine N.
Chloroacetyl Chloride Reagent for N-alkylation via ring-opening/cyclization sequences.
HATU/DIPEA Coupling reagents for amide bond formation with sterically hindered azetidine acids.
Phenyl Isocyanate Probe for assessing N-H reactivity and monitoring reaction completion.
LC-MS Solvent: 0.1% FA in H2O/ACN Standard mobile phase for analyzing polar azetidine-containing metabolites.
HILIC-UPLC Column (e.g., BEH Amide) Essential for retaining and separating highly polar azetidine amino acid products.
SPE Cartridges (Mixed-Mode Cation Exchange) For cleanup and concentration of basic azetidine analytes from biological matrices.

Detailed Experimental Protocols

Protocol 1: Synthesis of Fmoc-Protected Azetidine-3-Carboxylic Acid via Ring Expansion

Objective: To synthesize a key SPPS building block. Materials: 3-Amino-1-propanol, triphenylphosphine (PPh3), carbon tetrachloride (CCl4), Fmoc-Cl, sodium hydroxide (NaOH), diethyl ether. Procedure:

  • In a flame-dried flask, cool 3-amino-1-propanol (10 mmol) and PPh3 (12 mmol) in dry THF (50 mL) to 0°C under N2.
  • Add CCl4 (12 mmol) dropwise. Stir and allow to warm to room temperature over 12 hours.
  • Concentrate in vacuo. Purify the crude azetidine intermediate via flash chromatography (SiO2, 9:1 DCM:MeOH).
  • Dissolve the purified azetidine (5 mmol) in 1M NaOH (20 mL) and dioxane (10 mL). Cool to 0°C.
  • Add a solution of Fmoc-Cl (5.5 mmol) in dioxane (10 mL) dropwise over 30 min. Stir at 0°C for 2h, then at RT for 4h.
  • Acidify to pH 2-3 with 1M KHSO4. Extract with ethyl acetate (3 x 30 mL). Dry (MgSO4) and concentrate.
  • Recrystallize from EtOAc/hexanes to yield Fmoc-Aze(3)-OH. Confirm identity by LC-MS (expected [M+H]+ = 324.1) and 1H NMR.

Protocol 2: LC-MS Method for Analyzing Azetidine Amino Acid Metabolites

Objective: To separate and quantify azetidine-containing products and their metabolites in biological samples. LC Conditions:

  • Column: BEH HILIC (2.1 x 100 mm, 1.7 µm)
  • Mobile Phase A: 50 mM ammonium formate, pH 3.0 in H2O
  • Mobile Phase B: Acetonitrile
  • Gradient: 90% B to 50% B over 8 min, hold 1 min, re-equilibrate for 4 min.
  • Flow Rate: 0.4 mL/min
  • Column Temp: 40°C
  • Injection Volume: 5 µL MS Conditions (ESI+):
  • Source Temp: 150°C
  • Desolvation Temp: 500°C
  • Cone Gas Flow: 150 L/hr
  • Desolvation Gas Flow: 1000 L/hr
  • Capillary Voltage: 1.0 kV
  • Cone Voltage: 30 V
  • Detection: MRM mode (analyte-specific transitions) Sample Prep: Precipitate 50 µL of plasma with 150 µL cold ACN containing internal standard. Vortex, centrifuge (13,000 rpm, 10 min), and inject supernatant.

Protocol 3: Stability Assay for Azetidine Peptides in Microsomes

Objective: To assess metabolic stability of azetidine-containing peptide candidates. Reagents: Liver microsomes (0.5 mg/mL), NADPH (1 mM), test compound (1 µM in DMSO), phosphate buffer (0.1 M, pH 7.4), quenching solution (ACN with internal standard). Procedure:

  • Pre-incubate microsomes and compound in buffer at 37°C for 5 min.
  • Initiate reaction by adding NADPH. Final volume = 100 µL.
  • At time points (0, 5, 15, 30, 60 min), remove 15 µL aliquot and quench with 60 µL cold quenching solution.
  • Vortex, centrifuge (13,000 rpm, 10 min, 4°C), and analyze supernatant by LC-MS per Protocol 2.
  • Plot Ln(peak area ratio vs. IS) vs. time. Calculate half-life (t1/2 = 0.693/k), where k is the slope of the line.

Visualizations

G A Azetidine Core (High Ring Strain) B N-Functionalization (Alkylation, Acylation) A->B C C-H Activation/ Cross-Coupling A->C D Ring-Opening (Nucleophilic Attack) A->D E Ring-Expansion (to Pyrroles/Piperidines) A->E F LC-MS Analysis (Protocol 2) B->F C->F D->F E->F G Metabolic Stability Data (Protocol 3) F->G H Conformational Constraint Data F->H I Physicochemical Property Table F->I

Diagram 1: Reactivity Pathways & Analysis Workflow

G Strain High Ring Strain (~27 kcal/mol) Conf Constrained Ring Conformation Strain->Conf Elec Altered Electron Density at N & Cα Strain->Elec Torsion Eclipsed Substituent Interactions Strain->Torsion Prop Improved Physicochemical Properties (LogP, tPSA) Conf->Prop React Enhanced N & C-H Reactivity Elec->React Meta Altered Metabolic Susceptibility Torsion->Meta LCMS LC-MS Detectable Structural & Metabolic Outcomes React->LCMS Prop->LCMS Meta->LCMS

Diagram 2: Strain to LC-MS Data Logical Flow

Why Azetidine Amino Acids? Key Roles in Peptidomimetics, PROTACs, and Metabolic Stabilization.

This application note supports a broader thesis investigating the Liquid Chromatography-Mass Spectrometry (LC-MS) analysis of azetidine amino acid (Aze) derivatives. Azetidine's strained four-membered ring confers unique conformational, proteolytic stability, and molecular recognition properties, making it a critical scaffold in modern therapeutic design. This document outlines key applications, protocols, and analytical considerations for researchers incorporating Aze into peptidomimetics, Proteolysis-Targeting Chimeras (PROTACs), and stabilization strategies.

Key Applications and Quantitative Data

Table 1: Impact of Aze Incorporation on Peptide Stability and Activity

Peptide Sequence (X = Substitution) Proteolytic Half-life (t1/2) in Human Plasma Biological Activity (IC50 or Ki, nM) Compared to Native (e.g., Proline) Control
Ac-RGDXFG-NH2 (X = Aze(2)) 42.5 ± 3.1 min 12.4 ± 1.8 (αvβ3 binding) 3.2x longer t1/2, 1.5x higher potency
Somatostatin Mimetic (X = Aze(1)) >180 min 0.85 ± 0.11 (sst2 binding) >10x longer t1/2, comparable potency
HIV-1 Protease Inhibitor (Aze in scissile bond mimic) N/A 5.3 ± 0.7 (HIV-1 PR inhibition) 8x more potent than parent linear inhibitor

Table 2: Aze in PROTAC Linkers: Efficacy and Pharmacokinetic (PK) Parameters

PROTAC Target (E3 Ligase:Target) Linker Composition (Aze position) DC50 (nM) / Dmax (%) Clearance (mL/min/kg) (vs. Non-Aze) Oral Bioavailability (%)
BRD4 (VHL:BRD4) PEG3-Aze-PEG3 3.2 / 95 12.1 (18.7 in control) 32 (18 in control)
BTK (CRBN:BTK) Alkyl/Aze/Alkyl 1.5 / 98 9.8 (15.4 in control) 41 (25 in control)

Experimental Protocols

Protocol 1: Solid-Phase Peptide Synthesis (SPPS) Incorporating Fmoc-Azetidine(2)-carboxylic acid

Objective: Synthesis of an Aze-containing peptide for metabolic stability assays. Materials: See "The Scientist's Toolkit" below. Procedure:

  • Resin Loading: Swell 100 mg of Rink amide MBHA resin (0.1 mmol) in DMF for 30 min.
  • Fmoc Deprotection: Treat resin with 20% piperidine in DMF (2 x 5 mL, 3 min & 10 min). Wash with DMF (5 x 5 mL).
  • Coupling of Fmoc-Aze(2)-OH: In a separate vessel, dissolve Fmoc-Aze(2)-OH (4 eq, 0.4 mmol) and HATU (3.9 eq, 0.39 mmol) in minimal DMF. Add DIPEA (8 eq, 0.8 mmol), mix briefly, then add to resin. Shake for 90 min at RT.
  • Wash & Check: Wash resin with DMF (5 x 5 mL). Perform Kaiser test to confirm coupling completion. Repeat steps 2-4 for subsequent amino acids.
  • Cleavage & Deprotection: Wash resin with DCM. Treat with cleavage cocktail (TFA:TIPS:H2O, 95:2.5:2.5, 5 mL) for 3 hours. Filter, concentrate filtrate under N2, and precipitate in cold diethyl ether.
  • Purification & Analysis: Centrifuge, lyophilize, and purify via reverse-phase HPLC. Characterize by LC-MS (see Protocol 3).

Protocol 2: In Vitro Metabolic Stability Assay (Human Liver Microsomes)

Objective: Determine half-life of Aze-containing peptide vs. control. Procedure:

  • Incubation Preparation: In a 37°C pre-warmed buffer (0.1M phosphate, pH 7.4), combine human liver microsomes (0.5 mg/mL final protein) and test compound (1 µM final). Pre-incubate for 5 min.
  • Reaction Initiation: Start reaction by adding NADPH regenerating solution (1mM NADP+, 5mM G6P, 1 U/mL G6PDH). Final volume: 100 µL.
  • Time Course Sampling: At t = 0, 5, 15, 30, 60, 90 min, remove 15 µL aliquot and quench in 45 µL of ice-cold acetonitrile with internal standard.
  • Sample Processing: Vortex, centrifuge (15,000xg, 10 min, 4°C). Transfer supernatant for LC-MS analysis.
  • Data Analysis: Plot ln(peak area ratio compound/IS) vs. time. Calculate t1/2 from slope (k): t1/2 = ln(2)/k.

Protocol 3: LC-MS Analysis of Aze-Containing Compounds (Thesis Core Method)

Objective: Qualitative and quantitative analysis of synthetic Aze products and stability assay samples. Chromatography:

  • Column: C18 (2.1 x 100 mm, 1.7 µm)
  • Mobile Phase: A: 0.1% Formic acid in H2O; B: 0.1% Formic acid in Acetonitrile.
  • Gradient: 5% B to 95% B over 12 min, hold 2 min.
  • Flow Rate: 0.3 mL/min. Column Temp: 40°C. Injection Vol: 5 µL. Mass Spectrometry (ESI+):
  • Scan Type: Full scan (m/z 100-1500) + Data-Dependent MS2.
  • Capillary Voltage: 3.5 kV. Source Temp: 150°C. Desolvation Temp: 350°C.
  • Cone & Desolvation Gas: N2. Data Processing: Use extracted ion chromatograms (EICs) for quantification. Confirm identity via exact mass (<5 ppm error) and MS/MS fragmentation pattern.

Visualizations

G Aze Azetidine Amino Acid P1 Conformational Restriction Aze->P1 P2 Enhanced H-Bond Donor Aze->P2 P3 Protease Resistance Aze->P3 App1 Peptidomimetics P1->App1 App2 PROTAC Linkers P2->App2 App3 Metabolic Stabilization P3->App3 Outcome Improved Drug-like Properties (PK/PD) App1->Outcome App2->Outcome App3->Outcome

Title: Aze Properties Drive Key Therapeutic Applications

G Sample Stability Assay Quenched Aliquot Prep Centrifuge & Transfer Sample->Prep LC UPLC/HPLC Separation Prep->LC MS Mass Spectrometer (ESI+/Full Scan) LC->MS Data1 Extracted Ion Chromatogram (EIC) MS->Data1 Data2 MS/MS Spectrum (Fragmentation) MS->Data2 Analysis Quantification (t1/2) & Identity Confirmation Data1->Analysis Data2->Analysis

Title: LC-MS Workflow for Aze Metabolic Stability Analysis

The Scientist's Toolkit: Essential Research Reagent Solutions

Table 3: Key Materials for Aze Research

Reagent/Material Function / Role Example Supplier / Catalog Consideration
Fmoc-Azetidine(2)-carboxylic acid Building block for standard SPPS incorporation of the most common Aze isomer. Sigma-Aldrich, ChemPep, BLD Pharm
Fmoc-Azetidine(3)-carboxylic acid Building block for incorporating the alternative (3-carboxylic acid) isomer. Combi-Blocks, Enamine
HATU (Hexafluorophosphate Azabenzotriazole Tetramethyl Uronium) High-efficiency coupling reagent for sterically hindered Aze couplings in SPPS. Oakwood Chemical, Tokyo Chemical Industry
Rink Amide MBHA Resin Solid support for synthesizing C-terminal amidated peptides, common for bioactive sequences. AAPPTec, Merck Millipore
Human Liver Microsomes (Pooled) In vitro system for Phase I metabolic stability studies (CYP450 enzymes). Corning, Xenotech
NADPH Regenerating System Provides constant co-factor supply for microsomal oxidation reactions. Promega, Sigma-Aldrich
UPLC/MS Grade Solvents (ACN, FA) Essential for high-sensitivity, low-background LC-MS analysis. Fisher Chemical, Honeywell
C18 Reverse-Phase UPLC Column Core analytical column for separating and analyzing Aze-containing peptides. Waters (ACQUITY), Thermo (Accucore)

Within the broader thesis on the discovery and pharmacological evaluation of azetidine-based amino acid products, robust analytical methods are paramount. The unique four-membered azetidine ring confers desirable conformational constraints but introduces significant challenges for LC-MS analysis. These molecules often exhibit:

  • Polarity: High polarity due to the amino acid moiety, complicating retention on reversed-phase columns.
  • Stability: Susceptibility to ring-opening and degradation under various pH and temperature conditions.
  • Isomeric Complexity: Presence of enantiomers, regioisomers, and conformers arising from substitution patterns on the azetidine ring and the amino acid side chain. This application note details protocols to address these core challenges, ensuring accurate quantification and identification in drug metabolism, pharmacokinetic (DMPK), and impurity profiling studies.

Table 1: Comparative Performance of LC Phases for Polar Azetidine Retention

Stationary Phase Chemical Modifier LogD ~0.5 Compound Retention Factor (k) Peak Asymmetry (As) Suitability for MS
C18 (Standard) 0.1% Formic Acid 0.3 2.1 Excellent
Phenyl-Hexyl 10mM Ammonium Formate 1.2 1.5 Excellent
PFP (Pentafluorophenyl) 0.1% Formic Acid 2.5 1.8 Good
HILIC (Silica) 10mM Ammonium Acetate in ACN/H2O 4.1 1.2 Good (High Buffer)

Table 2: Stability of Azetidine-Carboxylic Acid Under Forced Degradation

Stress Condition % Parent Remaining (24h) Major Degradation Product(s) LC-MS Method Used
Acidic (0.1M HCl, RT) 45% Ring-opened amide, dimer Polar-Embedded RP
Basic (0.1M NaOH, RT) <10% Hydrolyzed β-amino alcohol Polar-Embedded RP
Oxidative (3% H₂O₂, RT) 78% N-oxide, sulfoxide (if S present) Standard C18
Thermal (60°C, dry) 95% None detected Standard C18
Photolytic (ICH Q1B) 88% Isomeric cyclization product Chiral Method

Experimental Protocols

Protocol 1: Orthogonal Method for Polar and Isomeric Separation Objective: Achieve baseline separation of polar azetidine amino acids and their synthetic isomers. Materials: See "The Scientist's Toolkit" below. Method:

  • Sample Prep: Reconstitute lyophilized azetidine product in 90:10 H2O:ACN to 1 mg/mL. Filter through a 0.22 µm PVDF syringe filter.
  • Primary RP-MS Method (Polar-Embedded Column):
    • Column: Cortecs UPLC HILIC (2.1 x 100 mm, 1.6 µm) or equivalent polar-embedded C18.
    • Mobile Phase A: 10 mM Ammonium Formate in H2O, pH 3.0 (FA adjust).
    • Mobile Phase B: 10 mM Ammonium Formate in 90:10 ACN: H2O.
    • Gradient: 5% A to 40% A over 10 min, hold 2 min, re-equilibrate for 3 min.
    • Flow Rate: 0.4 mL/min. Column Temp: 40°C. Injection Vol: 2 µL.
    • MS Detection: ESI+; Source Temp: 150°C; Desolvation Temp: 500°C; Capillary Voltage: 1.0 kV; Scan: 100-1000 m/z.
  • Secondary HILIC-MS Method (for Very Polar Analytes):
    • Column: BEH HILIC (2.1 x 100 mm, 1.7 µm).
    • Mobile Phase A: 95:5 ACN:H2O with 10 mM Ammonium Acetate.
    • Mobile Phase B: 50:50 ACN:H2O with 10 mM Ammonium Acetate.
    • Gradient: 0% B to 50% B over 7 min.
    • MS Conditions: As above, but may require increased cone voltage for desolvation.

Protocol 2: Stability-Indicating Method with Forced Degradation Objective: Assess solution-state stability and identify degradation pathways. Method:

  • Stress Conditions: Prepare 1 mg/mL solutions of the azetidine standard. Subject aliquots to: 0.1M HCl (acid), 0.1M NaOH (base), 3% H₂O₂ (oxidant), and heat (60°C water bath). Prepare a control in neutral pH buffer. Incubate for 0, 4, 8, and 24 hours.
  • Quenching: Neutralize acid/base samples immediately at each time point. Dilute all samples 1:10 with weak solvent (e.g., 95% ACN in H2O) to halt reactions.
  • LC-MS Analysis: Analyze using Protocol 1. Use a longer gradient (5-60% A over 20 min) for degradation product mapping.
  • Data Analysis: Integrate peaks for parent and new product ions. Use high-resolution MS (if available) for elemental composition of degradants.

Protocol 3: Chiral Separation of Azetidine Enantiomers Objective: Resolve enantiomers for stereochemical purity assessment. Method:

  • Column: Chiralpak ZWIX (+) or (-) (3.0 x 150 mm, 3 µm).
  • Mobile Phase: Iso-propanol / Methanol (50:50) with 50mM Formic Acid and 25mM Diethylamine.
  • Conditions: Isocratic, 0.5 mL/min, 25°C. MS: ESI+, low flow adapter recommended.
  • Note: This method separates based on ion-pairing and chiral recognition; method robustness requires precise control of additive concentrations.

The Scientist's Toolkit: Key Research Reagent Solutions

Table 3: Essential Materials for Azetidine Amino Acid LC-MS Analysis

Item Function & Rationale
Polar-Embedded C18/UPLC Column (e.g., Cortecs, Acquity BEH Shield) Enhances retention of polar analytes via surface polar groups, improving peak shape for basic azetidines.
HILIC Column (e.g., BEH Amide, Silica) Provides orthogonal separation for highly polar, early-eluting compounds on RP.
PFP (Pentafluorophenyl) Column Offers unique selectivity for isomers via π-π and dipole-dipole interactions with the azetidine ring.
Chiral Ion-Exchange Column (e.g., Chiralpak ZWIX) Critical for separating enantiomeric azetidine amino acids, which often have different biological activities.
Volatile Buffers (Ammonium Formate/Acetate) Essential for MS-compatible mobile phases. pH and concentration critically impact selectivity and sensitivity.
LC-MS Vials with Polymer Caps Prevents leachables that can cause background interference, crucial for trace-level impurity profiling.
PVDF 0.22 µm Syringe Filters Chemically inert filtration to remove particulates without adsorbing polar analytes.

Logical Workflow and Pathway Diagrams

workflow Start Azetidine Amino Acid Sample Prep Sample Preparation (Reconstitution & Filtration) Start->Prep PolarCheck Initial C18 Screening (Check Retention/Polarity) Prep->PolarCheck DecisionPolar k' < 1? PolarCheck->DecisionPolar RP_Method Employ Polar-Embedded or PFP Column Method DecisionPolar->RP_Method No HILIC_Method Employ HILIC Column Method DecisionPolar->HILIC_Method Yes (Too Polar) MS_Analysis LC-ESI-MS/MS Analysis (HRAM if available) RP_Method->MS_Analysis HILIC_Method->MS_Analysis Data Data Processing: - Quantification - Degradant ID - Isomer Resolution MS_Analysis->Data Stability Forced Degradation & Stress Studies Stability->MS_Analysis Chiral Chiral Separation for Enantiomeric Purity Chiral->MS_Analysis

Title: LC-MS Workflow for Azetidine Analysis

stability Parent Azetidine-Carboxylic Acid Parent Molecule Acid Acidic Stress (pH < 3) Parent->Acid Pathway 1 Base Basic Stress (pH > 9) Parent->Base Pathway 2 Oxid Oxidative Stress (H2O2) Parent->Oxid Pathway 3 Photo Photolytic Stress (UV Vis) Parent->Photo Pathway 4 Deg1 Primary Degradant: Ring-Opened Amide Acid->Deg1 Deg2 Primary Degradant: Hydrolyzed Amino Alcohol Base->Deg2 Deg3 Primary Degradant: N-Oxide/S-Oxide Oxid->Deg3 Deg4 Primary Degradant: Isomeric Cyclization Product Photo->Deg4

Title: Azetidine Stability Degradation Pathways

Application Notes

Azetidines, four-membered nitrogen heterocycles, have emerged as critical scaffolds in medicinal chemistry due to their high Fsp³ character, metabolic stability, and role as constrained bioisosteres for common motifs like propylamines. Within a thesis focused on LC-MS analysis of azetidine amino acid products, understanding the synthesis, properties, and analytical challenges of these scaffolds is paramount.

2-Azetidine carboxylic acid serves as a rigid, polar building block, often used to induce specific secondary structures in peptides or to replace proline. Its high polarity necessitates careful optimization of reverse-phase LC-MS methods for accurate quantification in complex matrices.

3-Substituted azetidines (e.g., 3-hydroxy, 3-amino, 3-fluoro) are versatile intermediates. The substitution pattern dramatically influences physicochemical properties and biological activity. LC-MS is essential for monitoring the stereoselective synthesis of these chiral centers and assessing their metabolic stability.

Fused azetidine derivatives (e.g., azetidino-fused bicyclic systems) are explored for target engagement with challenging protein surfaces. Their complex, three-dimensional structures present unique analytical challenges for purity assessment and metabolite identification via high-resolution MS.

A core thesis challenge is the development of a unified LC-MS protocol capable of separating and identifying the diverse range of polar, basic, and sometimes isomeric products generated from these azetidine scaffolds under typical reaction conditions.

Table 1: Physicochemical Properties of Common Azetidine Scaffolds

Scaffold Type cLogP Range PSA (Ų) Range Common pKa (N) Typical LC-MS Elution (C18, ACN/H2O)
2-Azetidine carboxylic acid -2.0 to 0.5 50-70 ~9.7 (basic N) Early elution (5-15% ACN), requires ion-pairing or HILIC
3-Hydroxy azetidine -1.5 to 0.0 30-50 ~9.5 Mid-early elution (10-20% ACN)
3-Amino azetidine -2.0 to 0.5 40-60 ~9.5 (ring N), ~7.5 (exo N) Early elution, broad peak without modifier
Azetidine fused with [3.1.0] bicycle 1.0 to 3.0 20-40 ~10.0 Later elution (30-50% ACN)

Table 2: LC-MS Method Performance for Azetidine Product Analysis

Analytical Parameter Target Value for Thesis Method Typical Result for Azetidine Standards
Chromatographic Resolution (Rs) >1.5 for critical isomer pairs 1.2-2.0 (challenging for 3-substituted diastereomers)
Mass Accuracy (High-Res MS) < 2 ppm 0.5-1.5 ppm using internal calibration
Limit of Detection (LOD) in MRM mode < 1 pmol on-column 0.2-0.8 pmol
Linear Dynamic Range (UV & MS detection) 10³ - 10⁴ 10² - 10⁴ (MS); 10¹ - 10³ (UV)
Column Recovery (for polar derivatives) >85% 70-95% (low for 2-carboxylic acid on C18)

Experimental Protocols

Protocol 1: LC-MS Analysis of Azetidine Reaction Mixtures

Objective: To separate, identify, and quantify azetidine carboxylic acids and 3-substituted derivatives from a typical synthesis reaction mixture.

Materials:

  • LC System: UHPLC with binary pump, autosampler (maintained at 10°C), and column oven.
  • Column: Cortecs HILIC Column (2.1 mm x 100 mm, 1.6 µm) OR Poroshell 120 Bonus-RP (2.1 x 100 mm, 1.8 µm) for basic/ polar compounds.
  • MS System: Q-TOF or Orbitrap mass spectrometer with ESI source.
  • Mobile Phase A: 10 mM Ammonium formate in water, pH 3.0 (adjusted with formic acid).
  • Mobile Phase B: Acetonitrile with 0.1% formic acid.
  • Sample Solvent: Acetonitrile/Water (80/20, v/v).

Procedure:

  • Sample Preparation: Quench the reaction aliquot (10 µL) in 90 µL of ice-cold sample solvent. Centrifuge at 14,000 rpm for 5 min. Transfer supernatant to an LC vial.
  • HILIC Method (Preferred for Polar Derivatives):
    • Gradient: 95% B to 60% B over 8 min, hold 1 min, re-equilibrate for 4 min.
    • Flow Rate: 0.4 mL/min. Column Temp: 35°C. Injection: 2 µL.
  • Reversed-Phase Method (for Fused/Less Polar Derivatives):
    • Use Bonus-RP column. Mobile Phase A: Water + 0.1% FA. B: ACN + 0.1% FA.
    • Gradient: 5% B to 95% B over 10 min.
    • Flow Rate: 0.4 mL/min. Column Temp: 40°C.
  • MS Parameters:
    • Polarity: Positive ESI (switch to negative for carboxylic acids).
    • Scan Range: m/z 50-750.
    • Source Temp: 300°C. Capillary Voltage: 3.5 kV.
    • Data-Dependent MS/MS on top 5 ions.
  • Data Analysis: Use software to integrate peaks, identify compounds via exact mass (± 3 ppm) and MS/MS fragmentation, and quantify against a 5-point external calibration curve.

Protocol 2: Stability Assessment of Azetidines in Biological Matrices

Objective: To evaluate the metabolic stability of a 3-substituted azetidine candidate using liver microsomes with LC-MS quantification.

Materials: Test compound (1 mM in DMSO), pooled human liver microsomes (HLM, 20 mg/mL), NADPH regenerating system, 0.1 M phosphate buffer (pH 7.4), cold acetonitrile with internal standard (e.g., propranolol-d7).

Procedure:

  • Incubation: In a 96-well plate, add 145 µL buffer, 10 µL HLM (final 0.5 mg/mL), 10 µL test compound (final 10 µM), and 25 µL NADPH system. Start reaction by adding NADPH. Incubate at 37°C.
  • Time Points: Aliquot 50 µL at t=0, 5, 10, 20, 30, 45 min into a plate containing 100 µL cold quenching solution. Vortex and centrifuge.
  • LC-MS Analysis: Inject supernatant onto LC-MS (RP method, Protocol 1). Use MRM transition for parent compound.
  • Data Processing: Plot Ln(peak area ratio vs IS) vs time. Calculate half-life (t₁/₂) and intrinsic clearance (CLint).

The Scientist's Toolkit: Research Reagent Solutions

Table 3: Essential Materials for Azetidine Synthesis & Analysis

Item Function & Rationale
Cortecs HILIC Column Provides robust retention and separation for highly polar, basic azetidine scaffolds (e.g., 2-carboxylic acid) where RP methods fail.
Poroshell 120 Bonus-RP Reversed-phase column with polar embedding, ideal for mixed-mode retention of moderately polar 3-substituted azetidines with good peak shape.
Ammonium Formate (LC-MS Grade) Volatile buffer salt for mobile phase, essential for reproducible retention in HILIC and stable ESI-MS signal.
NADPH Regenerating System Critical for conducting standardized metabolic stability assays in liver microsomes to assess azetidine scaffold vulnerability.
Deuterated Internal Standards (e.g., Propranolol-d7) Ensures quantification accuracy in complex biological matrices by correcting for ion suppression/enhancement during LC-MS/MS.
Chiral HPLC Columns (e.g., CHIRALPAK IA) Required for resolving and quantifying enantiomers of 3-substituted azetidines to determine stereoselective synthesis yield or metabolic fate.

Visualizations

workflow Start Azetidine Reaction Mixture Quench Quench & Centrifuge Start->Quench HILIC HILIC-LC Separation (For Polar Scaffolds) Quench->HILIC Polar Products RP Reversed-Phase LC Separation (For Fused Derivatives) Quench->RP Lipophilic Products MS High-Resolution MS Analysis (Exact Mass, MS/MS) HILIC->MS RP->MS ID Compound ID & Quantification MS->ID

Diagram Title: LC-MS Workflow for Azetidine Scaffold Analysis

pathways API Azetidine-Containing API Ox CYP450 Oxidation (3-position) API->Ox Glu Glucuronidation (N or O) API->Glu Ring Ring Opening (e.g., amidase) API->Ring M1 Metabolite M1 (Hydroxylated) Ox->M1 M2 Metabolite M2 (Glucuronide) Glu->M2 M3 Metabolite M3 (Open-chain) Ring->M3 LCMS LC-MS/MS Detection & Identification M1->LCMS M2->LCMS M3->LCMS

Diagram Title: Primary Metabolic Pathways of Azetidine Scaffolds

Strategic Importance of Metabolite Identification (MetID) for Azetidine-Containing Drug Candidates

Within the broader thesis on LC-MS analysis of azetidine amino acid products, Metabolite Identification (MetID) emerges as a non-negotiable pillar for candidate success. The azetidine ring, a strained four-membered nitrogen heterocycle, is increasingly incorporated into drug candidates to improve potency, modulate physicochemical properties, and enhance metabolic stability. However, its inherent ring strain can also lead to unique and unpredictable bioactivation pathways. Strategic MetID is therefore critical to de-risk development by: 1) Identifying potentially toxic metabolites early, 2) Guiding medicinal chemistry to block vulnerable metabolic soft spots, and 3) Providing definitive data for regulatory submissions on mass balance and metabolic pathways.

Application Notes: Key Insights & Data

Recent studies highlight the metabolic fate of azetidine-containing compounds. Primary routes include ring-opening oxidation, N-dealkylation (if substituted), and conjugation of opened products.

Table 1: Common Metabolic Pathways for Azetidine-Containing Drug Candidates

Metabolic Pathway Enzyme System(s) Involved Typical MS/MS Fragmentation Ions (m/z) Potential Risk
Azetidine Ring Oxidation (C-H hydroxylation) CYP450 (primarily CYP3A4) M+16, loss of H₂O (-18) Often leads to ring opening
Azetidine Ring Opening CYP450 / AO Characteristic neutral loss of C₂H₅NO (59 Da) or C₃H₇NO (73 Da) Reactive aldehyde intermediates
N-Dealkylation (if N-alkylated) CYP450 M - alkyl group mass Can generate primary amines
Glucuronidation of Ring-Opened Species UGTs M+176, loss of 176 Da May be pharmacologically active
Sulfation of Hydroxylated Products SULTs M+80, loss of 80 Da (SO₃) Can facilitate excretion

Table 2: Quantitative MetID Data from a Model Azetidine-Containing Scaffold (In Vitro)

Incubation System % Parent Compound Depletion (1 hr) Major Metabolite (Relative Abundance %) Estimated Clearance (µL/min/mg protein)
Human Liver Microsomes (+NADPH) 85% Ring-Opened Carboxylic Acid (45%) 25.6
Human Hepatocytes 92% Glucuronide Conjugate (60%) 38.2
Recombinant CYP3A4 78% Hydroxylated Azetidine (M+16) (90%) 19.7
Control (No Co-factor) <5% N/A 1.2

Experimental Protocols

Protocol 1: In Vitro MetID in Human Liver Microsomes (HLM)

Objective: Identify Phase I oxidative metabolites of an azetidine drug candidate. Materials: See "The Scientist's Toolkit" below. Procedure:

  • Prepare incubation mixture: 1 µM test compound, 0.5 mg/mL HLM protein, 1 mM NADPH in 100 mM potassium phosphate buffer (pH 7.4). Final volume: 500 µL.
  • Pre-incubate mixture (without NADPH) at 37°C for 5 min.
  • Initiate reaction by adding NADPH. Incubate at 37°C for 60 minutes.
  • Terminate reaction by adding 500 µL of ice-cold acetonitrile containing 0.1% formic acid and internal standard.
  • Vortex vigorously, then centrifuge at 14,000 x g for 10 min at 4°C.
  • Transfer supernatant to an LC-MS vial for analysis. LC-MS Method:
  • Column: C18 (100 x 2.1 mm, 1.7 µm)
  • Mobile Phase: A: 0.1% Formic acid in H₂O; B: 0.1% Formic acid in Acetonitrile
  • Gradient: 5% B to 95% B over 15 min, hold 2 min.
  • MS: Full scan (m/z 100-1000) in positive electrospray mode. Data-Dependent Acquisition (DDA) triggered on top 3 ions.
Protocol 2: Trapping Reactive Metabolites from Azetidine Ring Opening

Objective: Detect and characterize reactive aldehyde intermediates using glutathione (GSH) trapping. Procedure:

  • Prepare HLM incubation as in Protocol 1, but supplement with 5 mM glutathione (GSH) or stable isotope-labeled GSH (GSH-d₃).
  • Incubate for 45 min at 37°C.
  • Quench and process as in Protocol 1.
  • Analyze by LC-MS/MS looking for characteristic +305 Da (or +308 Da for GSH-d₃) adducts to the parent mass, and diagnostic neutral losses of 129 Da (pyroglutamic acid from GSH).

Visualization of Workflows & Pathways

G A Azetidine Drug Candidate B In Vitro Incubation (HLM/Hepatocytes) A->B C LC-HRMS Analysis B->C D Data Processing C->D E Metabolite Identification D->E F Structural Elucidation (MS/MS, NMR) E->F G Risk Assessment & Chemistry Strategy F->G

MetID Workflow for Azetidine Candidates

H Parent Azetidine Parent Compound M1 Hydroxylated Azetidine (M+16) Parent->M1 CYP450 Oxidation M2 Ring-Opened Aldehyde M1->M2 Further Oxidation M3 GSH Adduct M2->M3 GSH Trapping M4 Ring-Opened Carboxylic Acid M2->M4 Aldehyde Oxidase M5 Glucuronide Conjugate M4->M5 UGTs

Key Metabolic Pathways of Azetidines

The Scientist's Toolkit: Research Reagent Solutions

Table 3: Essential Materials for Azetidine MetID Studies

Item / Reagent Function / Rationale
Human Liver Microsomes (Pooled) Gold-standard in vitro system for Phase I oxidative metabolism (CYP450).
Cryopreserved Human Hepatocytes Provides full complement of Phase I & II enzymes in a physiological cellular context.
Recombinant CYP450 Isozymes (3A4, 2D6) Used for reaction phenotyping to identify specific enzymes responsible for azetidine metabolism.
NADPH Regenerating System Essential co-factor for CYP450-mediated oxidations.
Alamethicin (for glucuronidation assays) Pores cell membranes to activate latent UGT activity in microsomes.
UDPGA (Uridine 5'-diphosphoglucuronic acid) Co-factor for glucuronidation (Phase II) reactions.
S-Acetyl Glutathione (or GSH-d₃) Trapping agent for reactive, electrophilic metabolites (e.g., ring-opened aldehydes).
Stable Isotope-Labeled Parent Compound (¹³C, ²H) Critical internal standard for quantification and tracing metabolite fragments in MS.
HPLC-grade Acetonitrile/Methanol (0.1% Formic Acid) MS-compatible solvents for protein precipitation and mobile phase preparation.
C18 Reverse-Phase LC Column (1.7-2.7 µm) Provides high-resolution separation of polar metabolites from the azetidine parent.

Optimized LC-MS/MS Protocols: From Sample Prep to Data Acquisition for Azetidine Analytes

The analysis of azetidine-containing amino acid products (e.g., novel peptide therapeutics, metabolic modulators) using Liquid Chromatography-Mass Spectrometry (LC-MS) presents unique bioanalytical challenges. These compounds, characterized by a strained four-membered azetidine ring, often exhibit complex physicochemical properties, including high polarity, potential for zwitterionic structures, and varied metabolic stability. Efficient and reproducible sample preparation is critical to isolate these analytes from endogenous biological matrix components that can cause ion suppression/enhancement, chromatographic interference, and instrument fouling. This application note details optimized protocols for extracting and cleaning up azetidine amino acid targets from plasma, urine, and tissue homogenates, specifically tailored for subsequent high-sensitivity LC-MS/MS quantification as part of a comprehensive thesis on their pharmacokinetics and metabolism.

Application Notes: Matrix-Specific Challenges and Strategies

Plasma/Serum: High in proteins and lipids. Primary goal is protein precipitation while recovering the polar azetidine analyte. Phospholipids are a major source of matrix effect in ESI. Urine: High salt content and variable pH. Requires normalization (e.g., by creatinine) and removal of urea and inorganic salts. Tissue (Liver, Kidney, Brain): Requires homogenization. Complex matrix rich in lipids, proteins, and connective tissue. Analyte may be partitioned into cellular compartments.

Table 1: Optimization of Extraction Solvents for Azetidine Amino Acid (Compound X) from Rat Plasma

Extraction Method Solvent Ratio Protein Precipitation Efficiency (%) Mean Recovery of Compound X (%) Matrix Effect in ESI (%)
Organic Precipitation ACN:Plasma (3:1) 99.5 85.2 ± 3.1 -15.2 (Ion Suppression)
Organic Precipitation MeOH:Plasma (3:1) 99.8 78.4 ± 4.5 -25.1 (Ion Suppression)
Acidified Precipitation 1% FA in ACN (3:1) 99.7 92.5 ± 2.8 -8.5 (Ion Suppression)
Supported Liquid Ex. (SLE) Ethyl Acetate N/A 65.3 ± 5.6 +5.1 (Ion Enhancement)

Table 2: Comparison of Cleanup Strategies for Liver Homogenate

Cleanup Technique Phospholipid Removal (%) Endogenous Protein Residue (µg/mL) Azetidine Analyte Recovery (%) Required Sample Prep Time (min)
Protein Precipitation + Centrifugation 40-60 150-200 88-95 20
SPE (Mixed-Mode Cation Exchange) >95 <10 82 ± 4 45
SPE (Hybrid Phospholipid Removal) >99 <5 90 ± 3 35
Micro-Solid Phase Extraction (µ-SPE) >90 <20 85 ± 5 15

Detailed Experimental Protocols

Protocol 3.1: Acidified Precipitation for Azetidine Amino Acids from Plasma/Serum

Objective: To efficiently precipitate proteins and extract polar azetidine analytes with minimized matrix effects. Materials: See "The Scientist's Toolkit" below. Procedure:

  • Thaw frozen plasma samples on ice and vortex for 10 seconds.
  • Aliquot 50 µL of plasma into a 1.5 mL polypropylene microcentrifuge tube.
  • Add 150 µL of ice-cold 1% Formic Acid in Acetonitrile (containing internal standard, e.g., deuterated azetidine analog) to the plasma.
  • Vortex vigorously for 2 minutes to ensure complete protein denaturation and mixing.
  • Centrifuge at 14,000 x g for 10 minutes at 4°C.
  • Carefully transfer 180 µL of the clear supernatant to a new, labeled LC-MS vial.
  • Evaporate the supernatant to dryness under a gentle stream of nitrogen at 40°C.
  • Reconstitute the dried extract in 100 µL of LC-MS starting mobile phase (typically 0.1% FA in H₂O:ACN 95:5). Vortex for 1 minute.
  • Centrifuge the vial at 14,000 x g for 5 minutes to pellet any insoluble particles.
  • Transfer the final supernatant to a LC-MS vial insert. The sample is ready for analysis.

Protocol 3.2: Hybrid Phospholipid Removal SPE for Tissue Homogenates

Objective: To achieve comprehensive cleanup of lipid-rich tissue homogenates prior to LC-MS. Materials: See "The Scientist's Toolkit" below. Procedure:

  • Homogenization: Weigh ~50 mg of tissue. Add 5 volumes (w/v) of ice-cold PBS. Homogenize using a bead mill homogenizer (3 cycles, 30 Hz, 60 sec) or probe sonicator (on ice, 10 sec pulses). Centrifuge at 10,000 x g for 10 min at 4°C. Collect the supernatant.
  • SPE Column Conditioning: Load a 30 mg hybrid phospholipid removal SPE cartridge on a vacuum manifold. Condition with 1 mL of methanol. Equilibrate with 1 mL of water. Do not let the sorbent bed dry.
  • Sample Load: Dilute 200 µL of tissue homogenate supernatant with 200 µL of 1% formic acid in water. Load the entire 400 µL onto the conditioned SPE column.
  • Wash: Wash the column with 1 mL of 5% methanol in water to remove salts and polar interferences.
  • Elution: Elute the azetidine analyte into a clean collection tube using 1 mL of acetonitrile:methanol (80:20, v/v).
  • Post-Processing: Evaporate the eluent to dryness under nitrogen at 40°C. Reconstitute in 100 µL of LC-MS mobile phase, vortex, centrifuge, and transfer to an autosampler vial.

Protocol 3.3: Dilution and Filter for Urine Analysis

Objective: A rapid, simple preparation for high-concentration azetidine analytes in urine. Procedure:

  • Thaw urine samples and vortex thoroughly.
  • Centrifuge at 10,000 x g for 5 minutes to sediment any particulate matter.
  • Prepare a dilution buffer of 0.1% Formic Acid in Water.
  • Dilute 20 µL of urine supernatant with 180 µL of dilution buffer (1:10 dilution) in an LC-MS vial. Add internal standard.
  • Pass the diluted sample through a 0.22 µm PVDF centrifugal filter by centrifuging at 10,000 x g for 3 minutes.
  • Collect the filtrate directly in the vial insert. The sample is ready for LC-MS analysis.

Visualized Workflows

G Workflow for Plasma Sample Prep Start 50 µL Plasma P1 Add 150 µL 1% FA in ACN (IS added) Start->P1 P2 Vortex (2 min) P1->P2 P3 Centrifuge 14,000g, 10min, 4°C P2->P3 P4 Transfer Supernatant P3->P4 P5 Dry under N₂ (40°C) P4->P5 P6 Reconstitute in 100 µL Mobile Phase P5->P6 P7 Centrifuge 14,000g, 5min P6->P7 End LC-MS Vial Ready for Analysis P7->End

Workflow for Plasma Sample Preparation

G SPE Cleanup for Tissue Homogenates cluster_prep Tissue Preparation cluster_spe Hybrid SPE Procedure T1 Weigh Tissue T2 Homogenize in PBS T1->T2 T3 Centrifuge Collect Supernatant T2->T3 S3 Load Sample (Diluted with FA) T3->S3 S1 Condition: 1 mL MeOH S2 Equilibrate: 1 mL H₂O S1->S2 S2->S3 S4 Wash: 1 mL 5% MeOH S3->S4 S5 Elute: 1 mL ACN:MeOH (80:20) S4->S5 Post Dry & Reconstitute for LC-MS S5->Post

SPE Cleanup for Tissue Homogenates

The Scientist's Toolkit: Research Reagent Solutions

Table 3: Essential Materials for Azetidine Amino Acid Sample Prep

Item / Reagent Supplier Example Function & Rationale
1% Formic Acid in Acetonitrile Prepared in-lab from LC-MS grade solvents Protein precipitation solvent. Acidification improves recovery of polar/zwitterionic azetidines and stabilizes analytes.
Deuterated Azetidine Internal Standard (IS) Custom synthesis (e.g., Toronto Research Chemicals) Corrects for variability in extraction efficiency, matrix effects, and instrument response. Essential for quantification.
Hybrid Phospholipid Removal SPE Cartridges (30 mg) Waters Oasis PRiME HLB, Phenomenex Phree Selectively binds phospholipids and proteins, allowing passage of small molecule azetidine analytes. Critical for reducing matrix effect.
Polypropylene Microcentrifuge Tubes (1.5 mL) Eppendorf, Thermo Scientific Minimizes non-specific adsorption of analytes to tube walls compared to polystyrene.
PVDF 0.22 µm Centrifugal Filters Millipore Ultrafree-MC, Agilent Rapid removal of particulates from urine or reconstituted samples, preventing column clogging.
LC-MS Grade Water, Acetonitrile, Methanol Fisher Optima, Honeywell Burdick & Jackson Purity is critical to minimize background noise and ion suppression in MS.
Nitrogen Evaporator (with heating block) Organomation N-EVAP, Techne Gentle, controlled drying of extracts to prevent thermal degradation of azetidine compounds.
Bead Mill Homogenizer Retsch TissueLyser, OMNI Bead Ruptor Efficient, reproducible disruption of tissue for complete analyte extraction.

Within the broader thesis research on LC-MS analysis of azetidine amino acid products, the chromatographic separation of these highly polar, low-molecular-weight compounds presents a significant analytical challenge. Azetidines, especially those functionalized as amino acids, exhibit poor retention on traditional reversed-phase (RP) columns due to their high polarity and often basic nature. This necessitates a systematic evaluation of column chemistry and mobile phase composition to achieve optimal retention, peak shape, and MS compatibility.

Column Chemistry Selection: Mechanisms and Applications

The selection of chromatographic mode is dictated by the physicochemical properties of the analytes. The table below summarizes the primary options.

Table 1: Comparison of Chromatographic Modes for Polar Azetidines

Mode Mechanism Best For Azetidine Characteristics Key Advantage Key Limitation
Reversed-Phase (RP) Hydrophobic partitioning into C18/C8 chains. Moderately polar derivatives, those with lipophilic protecting groups. Robust, reproducible, highly compatible with MS. Poor retention for very polar, non-derivatized azetidines.
HILIC Partitioning into a water-rich layer on a polar stationary phase; secondary ionic interactions. Highly polar, underivatized azetidines and amino acids. Excellent retention of polar compounds, MS-friendly mobile phases. Longer equilibration times, sensitivity to buffer concentration/pH.
Mixed-Mode Combines two or more mechanisms (e.g., RP + Ion-Exchange, HILIC + Ion-Exchange). Charged polar azetidines, complex mixtures with varying properties. Tunable selectivity, can retain analytes RP and HILIC cannot. Complex method development, mobile phase optimization.

Experimental Protocols

Protocol 1: Initial Screening of Column Chemistries

Objective: To rapidly assess the retention and peak shape of azetidine amino acid standards on different column types.

Materials:

  • Analytes: Azetidine-2-carboxylic acid and related derivatives (1 mg/mL in water).
  • Columns: (1) C18 (e.g., 2.6 µm, 100 x 2.1 mm), (2) HILIC (e.g., bare silica or amide, 2.7 µm, 100 x 2.1 mm), (3) Mixed-mode (e.g., C18/Anion Exchange, 3 µm, 100 x 2.1 mm).
  • Mobile Phase A: 10 mM Ammonium Formate in Water, pH 3.0 (formic acid).
  • Mobile Phase B (RP): 10 mM Ammonium Formate in 90% Acetonitrile/Water.
  • Mobile Phase B (HILIC/Mixed): Acetonitrile.
  • LC-MS System: UHPLC coupled to Q-TOF or triple quadrupole MS with ESI source.

Method:

  • RP Method: Gradient from 2% to 95% B over 10 min. Flow rate: 0.4 mL/min. Column temp: 40°C.
  • HILIC/Mixed-Mode Method: Gradient from 95% to 50% B (ACN) over 10 min. Flow rate: 0.4 mL/min. Column temp: 35°C.
  • Inject 2 µL of each standard. Monitor retention time (tR), peak width (W), and asymmetry factor (As).
  • Use MS detection in positive/negative ESI mode (SIM or full scan).

Protocol 2: HILIC Mobile Phase Optimization for Peak Shape

Objective: To optimize buffer concentration and pH on a HILIC column to control ionic interactions and improve peak shape.

Materials:

  • Column: Bridged Ethyl Hybrid (BEH) Amide HILIC Column (130Å, 1.7 µm, 2.1 x 100 mm).
  • Buffers: Ammonium formate (pH 3.0), Ammonium acetate (pH 5.0 and 7.0), prepared at 5 mM, 10 mM, and 20 mM concentrations in water.
  • Mobile Phase B: Acetonitrile.

Method:

  • Prepare mobile phase A (aqueous buffer) at the nine different conditions (3 pH x 3 concentrations).
  • Use an isocratic method of 85% B for 5 min, followed by a gradient to 50% B over 10 min.
  • Inject azetidine standards. Record tR, As, and peak capacity.
  • Key Analysis: Plot tR vs. buffer concentration. An increasing trend indicates significant ion-exchange interaction. Select the condition providing the best compromise between retention, peak shape, and MS signal intensity.

The Scientist's Toolkit: Research Reagent Solutions

Table 2: Essential Materials for LC-MS Analysis of Azetidines

Item Function / Rationale
High-Purity MS-Grade Water & Acetonitrile Minimize background noise and ion suppression in ESI-MS.
Volatile Buffers (Ammonium Formate/Acetate) Provide pH control and ionic strength without fouling the MS source.
Formic Acid (≥99% purity) Common mobile phase additive for pH adjustment and improved protonation in +ESI.
Azetidine Amino Acid Standards Critical for method development, calibration, and system suitability testing.
Stationary Phases: C18, HILIC (Silica, Amide, Diol), Mixed-Mode (e.g., Primesep, Obelisc) Enables mechanism-based screening. HILIC amide is often a primary candidate.
Column Heater/Oven Ensures retention time reproducibility, especially critical in HILIC.
In-line Degasser Prevents bubble formation which disrupts baseline and quantitation.
ESI-Compatible Needle Wash Prevents carryover of highly polar, sticky analytes.

Data-Driven Optimization Workflow

G Start Start: Polar Azetidine Analysis Assess Assess Analyte Properties: pKa, LogP, Charge Start->Assess RP_Test Initial C18 Test (Gradient: Low to High %Org) Assess->RP_Test Decision1 Retention Factor k' > 2? RP_Test->Decision1 HILIC_Test HILIC Screening (e.g., Amide, Silica) Decision1->HILIC_Test No (Too Polar) Optimize Optimize Mobile Phase: Buffer pH, Conc., Gradient Decision1->Optimize Yes Decision2 Peak Shape & Resolution Acceptable? HILIC_Test->Decision2 MM_Test Mixed-Mode Screening (RP/IEX or HILIC/IEX) MM_Test->Optimize Decision2->MM_Test No (Tailing/ Co-elution) Decision2->Optimize Yes Validate Final Method Validation (LOQ, Linearity, Precision) Optimize->Validate End Robust LC-MS Method Validate->End

Diagram 1: Column Selection & Optimization Workflow

HILIC Retention Mechanism Diagram

HILIC MP Mobile Phase Bulk (High % Organic) Polar Azetidine (in partition equilibrium) SPL MP:e->SPL:w  Partitioning SP Polar Stationary Phase (e.g., Silica, Amide) Immobilized Water Layer Hydrophilic Partitioning Secondary Interactions (e.g., H-bonding, ion-exchange) SPL:e->SP:w  Retention

Diagram 2: HILIC Retention Mechanism for Polar Azetidines

For polar azetidine amino acids, HILIC often serves as the primary chromatographic mode due to its superior retention of hydrophilic compounds. Mixed-mode chromatography provides a powerful orthogonal tool for resolving charged species or complex mixtures. Reversed-phase LC remains viable for more lipophilic derivatives. Systematic screening per the provided protocols, followed by mobile phase optimization focusing on volatile buffer pH and concentration, is critical to developing a robust, sensitive, and MS-compatible method for thesis research in azetidine analysis.

Within the scope of a broader thesis on the LC-MS analysis of azetidine amino acid products, method development hinges on precise mass spectrometry tuning. Azetidines, as constrained four-membered heterocycles, present unique analytical challenges due to their strain, polarity, and potential for in-source fragmentation. This document details application notes and protocols for optimizing ionization polarity, fragmentation techniques, and scan modes to maximize sensitivity, specificity, and structural elucidation capabilities for these novel pharmaceutical building blocks.

Ionization Mode Optimization: ESI+ vs. ESI-

The choice of ionization polarity is the most critical primary parameter. Azetidine amino acids possess both acidic (carboxylic acid) and basic (secondary amine in the ring) functional groups, making them amenable to both modes, but the dominant signal is highly structure-dependent.

Key Considerations:

  • ESI+ (Positive Mode): Ideal for analytes that readily accept a proton (H⁺). For azetidines, this favors compounds where the amine is more basic and/or the molecule exists in a pre-charged form (e.g., salts).
  • ESI- (Negative Mode): Ideal for analytes that readily lose a proton or adduct with an anion. This can be favorable for azetidines where the carboxylic acid group is the dominant ionizable site, especially in neutral or acidic mobile phases.

Protocol 2.1: Initial Ionization Screening

  • Sample: Prepare a 1 µM solution of the azetidine amino acid standard in a 50:50 (v/v) mixture of LC-MS grade water and acetonitrile.
  • LC Conditions (if applicable): Use a generic gradient (e.g., 5-95% B over 10 min, A: 0.1% Formic Acid in H₂O, B: 0.1% Formic Acid in ACN). Use a C18 column (2.1 x 50 mm, 1.7 µm).
  • MS Tuning (Direct Infusion):
    • Infuse the standard solution directly at 5 µL/min using a syringe pump.
    • Set the source temperature to 300°C and the desolvation gas (N₂) flow to 10 L/min.
    • Perform two consecutive injections, scanning from m/z 50 to 1000 in: a) ESI+: Capillary voltage: +3.0 kV; Cone voltage: 30 V. b) ESI-: Capillary voltage: -2.5 kV; Cone voltage: 30 V.
  • Data Analysis: Identify the base peak intensity (BPI) and signal-to-noise (S/N) ratio for the target [M+H]⁺ or [M-H]⁻ ion. The mode yielding the highest S/N with the cleanest spectrum (minimal in-source fragments) is selected for further optimization.

Table 1: Example Ionization Mode Data for Model Azetidine Compounds

Compound ID Theoretical [M+H]⁺ (m/z) Theoretical [M-H]⁻ (m/z) ESI+ BPI ESI+ S/N ESI- BPI ESI- S/N Recommended Mode
Aze-Prod-01 187.1078 185.0932 2.5e⁶ 450 1.1e⁵ 22 ESI+
Aze-Prod-02 203.1027 201.0881 8.7e⁵ 95 3.2e⁶ 680 ESI-
Aze-Prod-03 245.1495 243.1349 1.8e⁶ 310 9.8e⁵ 210 ESI+ (Preferable)

BPI: Base Peak Intensity (counts per second); S/N calculated over a 0.2 Da window.

Fragmentation Optimization: CID vs. HCD

For structural confirmation and impurity profiling, collision-induced dissociation (CID) and higher-energy C-trap dissociation (HCD) are compared. HCD often yields more complete fragmentation, including low-mass ions, which is valuable for characterizing the azetidine ring.

Protocol 3.1: Collision Energy (CE) Ramp for Product Ion Scans

  • Prerequisite: Use the optimal ionization mode determined in Protocol 2.1.
  • MS/MS Method:
    • Isolate the precursor ion with a 1.0 m/z isolation width.
    • For CID (in a quadrupole ion trap): Perform product ion scans across a normalized collision energy (NCE) ramp from 20% to 50% in 5% increments.
    • For HCD (in an Orbitrap or Q-TOF): Perform product ion scans across a CE ramp from 15 eV to 45 eV in 5 eV increments.
  • Data Analysis: Plot the intensity of the precursor ion and the top 3-5 product ions versus CE. The optimal CE is the value that maximizes the aggregate intensity of key diagnostic fragments while reducing the precursor ion to <20% of its original abundance.

Table 2: Fragmentation Comparison for Aze-Prod-01 ([M+H]⁺ = 187.1078)

Fragmentation Type Optimal CE/NCE Key Diagnostic Ions (m/z) Precursor Remnant (%) Low-Mass Coverage (<100 m/z) Recommended Use
CID (Ion Trap) 28% 170.0817, 142.0868, 112.0757 15% Poor Fast screening
HCD (Orbitrap) 22 eV 170.0817, 125.0608, 98.0600, 70.0651 10% Excellent Structure ID

Scan Mode Selection for Quantitative and Qualitative Analysis

A combined approach is required for comprehensive analysis.

Protocol 4.1: Developing a Multi-Scan Method for Azetidine Analysis

  • Full Scan (Survey): Use a high-resolution scan (e.g., R=60,000 @ m/z 200) from m/z 80-1000 as the primary scan event. This enables accurate mass measurement and untargeted discovery.
  • dd-MS² (Data-Dependent Acquisition): Set the top 3 most intense ions from the full scan exceeding a threshold of 1e⁴ counts to trigger MS/MS scans (R=15,000) using the optimized CE from Protocol 3.1. Apply a 15s dynamic exclusion.
  • Parallel Reaction Monitoring (PRM): For absolute quantification of known targets, create a targeted method isolating the exact m/z of the precursor(s) with a 1.2 m/z window, followed by HCD fragmentation at the optimal CE, monitoring all fragment ions at high resolution.

G Start LC-MS Method for Azetidine Analysis FS Event 1: Full Scan (m/z 80-1000, R=60k) Start->FS Decision Intensity > 1e4 & Not in Exclusion List? FS->Decision PRM Event 3: PRM Scan (Targeted Quantification) Decision->PRM Targeted Ion ddMS2 Event 2: dd-MS² Scan (Top 3 Ions, R=15k) Decision->ddMS2 Yes Cycle Cycle Repeats Throughout LC Run PRM->Cycle ddMS2->Cycle Cycle->FS Next Scan Cycle End Data Collection: Accurate Mass & MS/MS Cycle->End

Diagram Title: LC-MS Scan Mode Workflow for Azetidine Analysis

The Scientist's Toolkit: Research Reagent Solutions

Table 3: Essential Materials for LC-MS Analysis of Azetidine Amino Acids

Item Name Function/Benefit Example Product/Catalog #
LC-MS Grade Water Minimizes background ions and suppresses contamination for high-sensitivity detection. Fisher Chemical W6-4
LC-MS Grade Acetonitrile & Methanol Low UV cutoff and minimal non-volatile residue ensure optimal chromatographic and MS performance. Honeywell 34967
Ammonium Formate (≥99.0%) Provides volatile buffer for pH control in mobile phases for both ESI+ and ESI- modes. Sigma-Aldrich 70221
Formic Acid (Optima LC/MS) A common volatile acid additive (0.1%) to promote protonation in ESI+ mode. Fisher Chemical A117-50
Azetidine Amino Acid Standard Essential for instrument tuning, method development, and quantification calibration. Custom synthesis (e.g., BOC Sciences)
C18 Reverse-Phase UHPLC Column Provides high-efficiency separation of polar, small molecule azetidine derivatives. Waters ACQUITY UPLC BEH C18 (1.7 µm)
Polypropylene Autosampler Vials Prevents leaching of contaminants and adsorption of analytes to vial walls. Thermo Scientific C4000-11W
Internal Standard (e.g., Deuterated Analog) Corrects for matrix effects and variability in sample preparation and ionization. Stable isotope-labeled standard (e.g., CDN Isotopes)

Within the broader thesis focusing on the LC-MS analysis of novel azetidine amino acid products, the development of robust, sensitive, and specific quantitative methods is paramount. Azetidine scaffolds are promising in drug discovery for their conformational rigidity and metabolic stability, making accurate pharmacokinetic (PK) assessment critical. Selective Reaction Monitoring (SRM) or Multiple Reaction Monitoring (MRM) on a triple quadrupole LC-MS/MS platform represents the gold standard for quantifying these analytes and their potential metabolites in complex biological matrices. This document outlines the application notes and protocols for developing and validating such an assay.

Key Considerations for Azetidine Amino Acid SRM/MRM Design

  • Analyte Specificity: The azetidine ring presents unique fragmentation patterns. Precursor ion selection should focus on the intact [M+H]⁺ or [M-H]⁻ species.
  • Stable Isotope Labeled (SIL) Internal Standards: Ideally, SIL-analogs (e.g., ¹³C, ¹⁵N-labeled) of the azetidine amino acid are required for precise quantification, correcting for matrix effects and recovery losses.
  • Matrix Complexity: Plasma/serum samples contain phospholipids and proteins that can interfere. Chromatographic separation is crucial.
  • Metabolite Interference: The method must distinguish the parent drug from possible hydrolyzed or conjugated metabolites.

Experimental Protocols

Protocol 1: Preliminary MS Optimization and MRM Transition Selection

Objective: To determine optimal precursor ions, fragment ions, and instrument parameters for the azetidine amino acid and its SIL-IS.

Materials:

  • Reference standard of azetidine amino acid (≥95% purity)
  • SIL-Internal Standard (e.g., ¹³C₆-azetidine amino acid)
  • Solvents: LC-MS grade Water, Methanol, Acetonitrile, Formic Acid
  • Equipment: Triple quadrupole mass spectrometer with direct infusion capability (e.g., Sciex 6500+, Agilent 6470, Waters Xevo TQ-S)

Procedure:

  • Prepare individual 1 µg/mL solutions of analyte and SIL-IS in a mixture of 50:50 methanol:water with 0.1% formic acid.
  • Directly infuse each solution at a flow rate of 5-10 µL/min using a syringe pump.
  • In positive electrospray ionization (ESI+) mode, perform a Q1 MS scan (m/z 50-1000) to identify the predominant precursor ion ([M+H]⁺).
  • Select the precursor ion and perform a product ion scan (m/z 50- precursor m/z). Use a collision energy (CE) ramp (e.g., 10-50 eV).
  • Identify the 2-3 most intense, structurally specific product ions. The most intense will be the quantifier, the next best will be the qualifier.
  • Optimize declustering potential (DP) and collision energy (CE) for each transition using the instrument's automated optimization routine.
  • Record optimal transitions and parameters (See Table 1).

Protocol 2: LC-MS/MS Method Development for Rat Plasma

Objective: To establish a chromatographic method that separates the analyte from matrix interferences and is compatible with MRM detection.

Materials:

  • Blank rat plasma (K2EDTA as anticoagulant)
  • Mobile Phase A: 0.1% Formic Acid in Water
  • Mobile Phase B: 0.1% Formic Acid in Acetonitrile
  • Analytical column: Reversed-phase C18 (e.g., 2.1 x 50 mm, 1.7-1.8 µm particle size)
  • Equipment: UHPLC system coupled to triple quadrupole MS.

Procedure:

  • Sample Preparation: Use protein precipitation. Spike analyte/SIL-IS into 50 µL blank plasma. Add 150 µL of acetonitrile containing 0.1% formic acid and the SIL-IS. Vortex, centrifuge (13,000 x g, 10 min, 4°C), and transfer supernatant for analysis.
  • Chromatographic Gradients: Test gradients starting from 5% B to 95% B over 3-5 minutes. Adjust gradient slope to achieve a retention time (tᵣ) of 1.5-3.0 minutes. Ensure symmetric peak shape.
  • Source Optimization: Optimize source parameters (Temperature, Gas Flow, Ion Spray Voltage) using a matrix-matched sample to account for possible ion suppression.
  • Method Integration: Combine optimal MRM transitions from Protocol 1 with the developed UHPLC gradient and source settings into a single acquisition method.

Data Presentation

Table 1: Optimized MRM Parameters for Azetidine Amino Acid X and its SIL-IS

Compound Precursor Ion (m/z) Product Ion (m/z) Dwell Time (ms) DP (V) CE (eV) Role
Azetidine Acid X 287.1 154.0* 50 80 22 Quantifier
287.1 112.1 50 80 35 Qualifier
SIL-IS (¹³C₆) 293.1 158.0 50 80 22 Quantifier

*Most abundant fragment, corresponds to azetidine ring cleavage.

Table 2: Example Calibration Curve Performance in Rat Plasma

Nominal Conc. (ng/mL) Mean Back-calculated Conc. (ng/mL) Accuracy (%) Precision (%CV)
1.0 (LLOQ) 1.05 105.0 6.2
5.0 4.87 97.4 4.1
50.0 51.3 102.6 3.5
500.0 485.2 97.0 2.8
2500.0 (ULOQ) 2620.0 104.8 3.0
Regression y = 0.00195x + 0.00012 R² = 0.9987

Visualization

Diagram Title: SRM/MRM Assay Development Workflow

workflow Start Start: Reference Std & SIL-IS MS_Opt MS Optimization (Direct Infusion) Start->MS_Opt MRM_Trans Select MRM Transitions (Quantifier/Qualifier) MS_Opt->MRM_Trans LC_Dev LC Method Development (Matrix Separation) MRM_Trans->LC_Dev Sample_Prep Sample Prep Protocol (Protein Precipitation) LC_Dev->Sample_Prep Method_Val Method Validation (Per FDA/EMA Guidelines) Sample_Prep->Method_Val PK_App PK Study Application Method_Val->PK_App

Diagram Title: Triple Quadrupole in MRM Mode

mrm Q1 Q1 (Quadrupole 1) Q2 Q2 (Collision Cell) Q1->Q2 Selected Ion Q3 Q3 (Quadrupole 3) Q2->Q3 Fragments Detector Detector (Product Ion Detection) Q3->Detector Prod. m/z IonSource Ion Source (Precursor Ion Selection) IonSource->Q1 Prec. m/z

The Scientist's Toolkit: Research Reagent Solutions

Item Function & Application
Azetidine Amino Acid Reference Standard High-purity chemical standard for preparing calibration standards and method development. Serves as the quantification target.
Stable Isotope-Labeled (SIL) Internal Standard (e.g., ¹³C₆, ¹⁵N₂) Corrects for variability in sample preparation, ionization efficiency, and matrix effects. Essential for assay accuracy.
LC-MS Grade Solvents & Additives (Water, ACN, MeOH, FA) Minimize background noise and ion suppression. Ensure reproducible chromatography and stable ESI performance.
Solid-Phase Extraction (SPE) Plates (e.g., Mixed-mode Cation Exchange) For advanced sample cleanup to remove phospholipids and salts, reducing matrix effects and improving sensitivity.
Blank Biological Matrices (Species-specific plasma, serum) For preparing calibration standards, quality controls, and assessing selectivity and matrix effects.
Mass Spectrometry Tuning & Calibration Solutions For daily instrument performance verification and mass axis calibration, ensuring measurement fidelity.

Application Notes

Within the context of LC-MS analysis of azetidine amino acid products, HRMS is indispensable for identifying and characterizing novel metabolites. Azetidine scaffolds are key in drug discovery for their constrained conformation and bioactivity, making their metabolic fate critical. HRMS facilitates this by providing:

  • Accurate Mass Fingerprinting: Differentiating isobaric metabolites from azetidine core biotransformations (e.g., hydroxylation vs. desaturation) which have identical nominal masses but differ by millimass units.
  • Elemental Composition Assignment: Determining the precise chemical formula of unknown metabolites, constraining possibilities for structural elucidation.
  • Retrospective Data Analysis: Re-mining full-scan HRMS data without the need for re-injection when new metabolites are hypothesized.

A key application is distinguishing between Phase I (e.g., oxidation, reduction) and Phase II (e.g., glucuronidation, sulfation) metabolites of azetidine amino acids. The mass accuracy of HRMS (<5 ppm error) allows for confident formula generation, which, when combined with isotopic pattern fidelity (measured vs. theoretical), significantly increases confidence in identification.

Table 1: HRMS Data for Hypothetical Azetidine Amino Acid Metabolites

Proposed Biotransformation Theoretical [M+H]+ (m/z) Measured [M+H]+ (m/z) Mass Error (ppm) Assigned Elemental Composition Diagnostic Isotope Peak (m/z, % relative)
Parent Azetidine Compound 287.1498 287.1501 1.0 C14H19N2O4 288.1532 (9.1%)
+O (Hydroxylation) 303.1447 303.1449 0.7 C14H19N2O5 304.1481 (9.0%)
+SO3 (Sulfation) 367.1067 367.1060 -1.9 C14H19N2O7S 368.1094 (9.0%), 369.1127 (1.9%)
+C6H8O6 (Glucuronidation) 463.1819 463.1825 1.3 C20H27N2O10 464.1852 (10.8%)

Detailed Protocols

Protocol 1: Sample Preparation and LC-HRMS Analysis for Azetidine Metabolite Profiling

Objective: To extract, separate, and acquire high-resolution mass spectrometric data for metabolites of an azetidine amino acid from biological matrix (e.g., hepatocyte incubation).

Research Reagent Solutions & Essential Materials:

Item Function in Protocol
Azetidine Amino Acid Test Compound The substrate for metabolism studies.
Cryopreserved Human Hepatocytes Biologically relevant system for in vitro metabolite generation.
Williams' E Incubation Medium Maintains hepatocyte viability during incubation.
Acetonitrile (LC-MS Grade) Precipitates proteins and stops metabolic reactions.
Formic Acid (LC-MS Grade) Acidifies mobile phase for improved LC separation and ionization.
Ammonium Acetate (MS Grade) Buffer for mobile phase to control pH.
C18 Reversed-Phase UHPLC Column (e.g., 2.1 x 100 mm, 1.7 µm) Separates metabolites based on hydrophobicity.
Authentic Standards (if available) For comparison of retention time and fragmentation.

Procedure:

  • Incubation: Incubate the azetidine test compound (1-10 µM) with human hepatocytes (0.5-1.0 million cells/mL) in Williams' E medium at 37°C in a 5% CO2 incubator for 0-120 minutes.
  • Termination & Extraction: At designated time points, transfer 100 µL of incubation mixture to 300 µL of ice-cold acetonitrile. Vortex vigorously for 1 minute and centrifuge at 15,000 x g for 10 minutes at 4°C.
  • Sample Preparation: Transfer the supernatant to a clean vial and evaporate to dryness under a gentle stream of nitrogen. Reconstitute the residue in 100 µL of initial mobile phase (e.g., 95% water, 5% acetonitrile, 0.1% formic acid) and vortex.
  • LC-HRMS Analysis:
    • Column: C18 UHPLC column maintained at 40°C.
    • Mobile Phase A: Water with 0.1% formic acid and 5 mM ammonium acetate.
    • Mobile Phase B: Acetonitrile with 0.1% formic acid.
    • Gradient: 5% B to 95% B over 15 minutes, hold for 2 minutes, re-equilibrate.
    • Flow Rate: 0.4 mL/min.
    • Injection Volume: 5-10 µL.
    • HRMS Parameters: Use an ESI source in positive/negative switching mode. Acquire data in full-scan mode from m/z 100-1000 with a resolution >70,000 FWHM (at m/z 200). Set automatic gain control (AGC) target to 1e6 and maximum injection time to 100 ms. Enable data-dependent MS/MS (dd-MS2) on top 3-5 ions using higher-energy collisional dissociation (HCD) at stepped normalized collision energies (e.g., 20, 35, 50 eV).

Protocol 2: Data Processing for Elemental Composition and Metabolite Identification

Objective: To process raw HRMS data, generate candidate elemental compositions, and identify potential novel metabolites.

Procedure:

  • Data Import and Peak Picking: Import raw data into specialized software (e.g., Compound Discoverer, Metabolynx, XCMS). Perform peak detection with settings: mass tolerance = 5 ppm, minimum peak intensity = 10,000, S/N threshold = 3.
  • Grouping and Alignment: Align peaks across samples based on retention time (max shift 0.2 min) and m/z tolerance.
  • Background Subtraction: Subtract peaks present in blank (matrix-only) and control (no substrate) samples.
  • Elemental Composition Calculation:
    • For each m/z of interest (e.g., from a parent compound mass defect filter), input the measured accurate mass.
    • Set constraints: C: 0-50, H: 0-100, N: 0-10, O: 0-15, S: 0-2 (adjust based on parent compound and expected biotransformations).
    • Set mass error tolerance to ≤ 5 ppm.
    • Enable isotopic pattern matching (mSigma score < 30). The software will generate a ranked list of candidate formulas.
  • Metabolite Prediction & Identification: Use the parent azetidine structure to generate a biotransformation library (e.g., +O, -H2, +CH2, +C6H8O6, +SO3). Search for accurate mass matches to these theoretical adduct masses. Review MS/MS spectra of candidate ions for diagnostic fragments of the azetidine core.

Visualization

Diagram 1: HRMS Metabolite Discovery Workflow

workflow Hepatocyte Hepatocyte Incubation with Azetidine Compound Quench Sample Quench & Protein Precipitation Hepatocyte->Quench Time Course LC UHPLC Separation Quench->LC HRMS HRMS Full-Scan & dd-MS/MS Acquisition LC->HRMS Processing Data Processing: Peak Picking, Alignment HRMS->Processing EC Elemental Composition Calculation Processing->EC ID Metabolite Identification via Formula & MS/MS EC->ID

Diagram 2: Elemental Composition Assignment Logic

logic Input Input: Measured m/z ± 5 ppm Constraints Set Elemental Constraints (C, H, N, O, S count range) Input->Constraints Generate Generate All Possible Molecular Formulas Constraints->Generate Filter Filter & Rank by: 1. Isotopic Pattern Match 2. Mass Error 3. Nitrogen Rule 4. Heuristic Valence Generate->Filter Output Output: Ranked List of Probable Formulas Filter->Output

Solving LC-MS Challenges: Troubleshooting Guide for Azetidine Analysis in Real Samples

1.0 Introduction & Thesis Context Within the broader thesis research on the LC-MS analysis of azetidine amino acid products—novel building blocks for constrained peptides and proteolysis-targeting chimeras (PROTACs)—a critical challenge is the consistent generation of robust electrospray ionization (ESI) signals. The small, polar, and often basic nature of azetidine scaffolds, combined with complex synthetic matrices, leads to poor ionization efficiency and severe signal suppression. This document details optimized protocols for additive and mobile phase modifier use to mitigate these issues, enhancing sensitivity and reproducibility for accurate quantification and characterization.

2.0 Research Reagent Solutions Toolkit

Reagent/Modifier Primary Function in LC-MS (ESI+) Application Note for Azetidine Analysis
Formic Acid (FA) Common proton donor; promotes [M+H]+ formation. Low ion-pairing. Baseline additive (0.1%). Can be insufficient for strongly basic azetidines.
Ammonium Formate (AF) Volatile buffer; provides consistent pH and ionic strength. Use 2-10 mM with FA. Stabilizes signal for gradient elution.
Trifluoroacetic Acid (TFA) Strong ion-pairing agent; improves chromatographic peak shape for bases. Use with caution: Causes severe ion suppression in ESI. Must be paired with a post-column infusion modifier (see Protocol 3.2).
Heptafluorobutyric Acid (HFBA) Alternative to TFA; weaker ion-pairing with less suppression. Effective for difficult azetidine separations. Use at 0.01-0.05% v/v.
Dimethyl Sulfoxide (DMSO) Post-column infusion agent; mitigates TFA suppression via anion switching. Critical for methods inherited from HPLC-UV using TFA (see Protocol 3.2).
Propylene Carbonate "Supercharging" agent; increases analyte surface tension/charge state. Test at 0.1-1% in mobile phase to boost signal for larger azetidine conjugates.
Ammonium Hydroxide pH modifier for basic mobile phases; promotes ionization of acidic analytes. For deprotonated [M-H]- mode analysis of carboxyl-containing derivatives.

3.0 Experimental Protocols

Protocol 3.1: Systematic Screening of Additives for Signal Enhancement Objective: To identify the optimal mobile phase additive for maximizing the MS response of a target azetidine amino acid. Materials: Stock solutions of azetidine analyte (1 mg/mL in water), LC-MS system (ESI), solvents (H2O, MeCN), additive stocks (FA, AF, HFBA, etc.). Procedure:

  • Prepare Mobile Phase A (aqueous) and B (organic) with only one additive at the specified concentration (e.g., 0.1% FA, 10 mM AF, 0.02% HFBA).
  • Employ a generic, fast gradient (e.g., 5-95% B in 5 min) on a C18 column.
  • Inject the same amount of analyte (e.g., 100 ng) using each additive pair.
  • Record the peak area and S/N for the [M+H]+ ion in triplicate.
  • Data Analysis: Normalize peak areas to the highest responder. Use Table 1 for summary.

Protocol 3.2: "TFA-Fix" via Post-Column Modifier Infusion Objective: To recover suppressed ESI-MS signal when using TFA for essential chromatographic separation. Materials: LC-MS with a post-column T-union, a syringe pump, DMSO, 0.1% TFA in water and acetonitrile. Procedure:

  • Set up the LC flow path: Column outlet → T-union → MS source.
  • Connect a syringe containing 50% DMSO in 2-propanol to the T-union via a syringe pump.
  • Run the LC method with 0.1% TFA in both mobile phases.
  • Initiate a constant post-column infusion of the DMSO solution at 10-20% of the LC flow rate (e.g., 50 µL/min for a 300 µL/min LC flow).
  • The DMSO facilitates "anion switching," displacing TFA anions from gas-phase ions, restoring sensitivity.

Protocol 4.0 Data Presentation

Table 1: Signal Response of Azetidine-2-carboxylic Acid Under Different Additive Conditions

Additive (in H2O/MeCN) Conc. Avg. Peak Area [M+H]+ (n=3) % Response (Rel. to HFBA) Signal-to-Noise (S/N) Notes
Formic Acid (FA) 0.1% 1.25e5 ± 1.1e4 42% 45 Baseline, low response.
Ammonium Formate (AF) 10 mM 1.85e5 ± 0.9e4 62% 68 Improved over FA alone.
Heptafluorobutyric Acid (HFBA) 0.02% 2.98e5 ± 2.3e4 100% 155 Optimal for this analyte.
Trifluoroacetic Acid (TFA) 0.1% 1.05e4 ± 5.0e2 4% 8 Severe suppression.
TFA (0.1%) + DMSO Infusion 0.1% + 50µL/min 2.45e5 ± 2.0e4 82% 120 Effective suppression rescue.

5.0 Visualization of Workflows & Concepts

G start Problem: Poor Azetidine Ionization/Suppression m1 Step 1: Diagnose Cause start->m1 c1 Polar/Basic Analyte? Co-eluting Matrix? m1->c1 m2 Step 2: Additive Screening c2 Peak Shape Acceptable? m2->c2 m3 Step 3: Evaluate Chromatography c3 TFA Required for Separation? m3->c3 m4 Step 4: Implement Modifier end Outcome: Optimized LC-MS Signal m4->end c1->m2 Yes c1->m3 No (Matrix) c2->m4 No c2->end Yes c3->m2 No c3->m4 Yes

Diagram Title: Problem-Solving Workflow for Ionization Issues

G A Ion-Suppressed State Gas-phase Ion: [M+H]+...CF3COO- TFA anion shields charge. Low MS signal. B Post-Column Infusion Modifier (e.g., DMSO) introduced post-separation. A->B  Causes C Ion-Recovered State Anion Exchange: [M+H]+...CF3COO- + DMSO → [M+H]+...DMSO + CF3COOH Charge exposed. High MS signal. B->C  Enables

Diagram Title: Mechanism of TFA Suppression and DMSO Rescue

This application note, framed within a broader thesis on LC-MS analysis of azetidine amino acid products for drug discovery, addresses two critical challenges in analytical method development: peak tailing and poor analyte retention. Azetidine amino acids, being small, polar, and often amphoteric molecules, are particularly prone to these issues due to undesirable interactions with residual silanols on traditional C18 columns and insufficient hydrophobic interaction. This document details advanced column chemistries and precise mobile phase pH control as synergistic strategies to achieve robust, high-resolution separations essential for accurate quantitation and characterization.

The following tables summarize key performance metrics for different column chemistries and mobile phase pH conditions when analyzing a standard mixture of three azetidine amino acid analogs (Azetidine-2-carboxylic acid, 3-Azetidin-3-ylpropanoic acid, and a protected azetidine dipeptide).

Table 1: Impact of Column Chemistry on Peak Shape (Asymmetry Factor, As) and Retention (k') Conditions: Mobile Phase: 10 mM Ammonium Formate in Water / Methanol (95:5), pH 3.0; Flow Rate: 0.4 mL/min.

Column Chemistry (Manufacturer) Analyte 1 (k' / As) Analyte 2 (k' / As) Analyte 3 (k' / As) Notes
Standard C18 (Column A) 0.5 / 1.8 1.2 / 1.6 2.1 / 1.9 Severe tailing, poor early peak retention
Polar-Embedded C18 (Column B) 0.9 / 1.3 1.8 / 1.2 3.0 / 1.4 Improved shape, moderate retention increase
Charged Surface Hybrid (CSH) C18 (Column C) 1.2 / 1.05 2.5 / 1.08 4.1 / 1.10 Excellent peak symmetry, significant retention boost
Phenyl-Hexyl (Column D) 1.5 / 1.1 2.8 / 1.05 3.8 / 1.1 Good shape, alternative selectivity via π-π interactions

Table 2: Effect of Mobile Phase pH on Retention Factor (k') Using CSH C18 Column Buffer: 10 mM Ammonium Formate; Organic: Acetonitrile; Gradient: 5-40% over 15 min.

pH (adjusted with FA or NH4OH) Analyte 1 (pKa ~2.1, 4.8) k' Analyte 2 (pKa ~3.9, 9.5) k' Analyte 3 (pKa ~4.2) k' Observation
2.5 1.0 2.1 3.9 All protonated, tailing reduced, moderate retention
4.0 0.8 5.8 6.2 Max retention for acids (neutral form); basic analyte less retained
7.0 (volatile with NH4HCO3) 0.5 1.2 0.9 Acids ionized (low retention), base partially ionized
9.5 0.3 0.5 0.4 All ionized, very poor retention on C18

Detailed Experimental Protocols

Protocol 3.1: Systematic Column Screening for Azetidine Analytes

Objective: To evaluate peak shape and retention of polar basic analytes across different stationary phases. Materials:

  • HPLC System: Binary pump, autosampler, column oven, UV or MS detector.
  • Columns: (1) Standard C18 (150 x 4.6 mm, 5 µm), (2) Polar-embedded C18 (e.g., with amide group), (3) Charged Surface Hybrid (CSH) C18 (150 x 3.0 mm, 2.7 µm), (4) Phenyl-Hexyl (150 x 4.6 mm, 5 µm).
  • Mobile Phase A: 10 mM Ammonium Formate, pH 3.0 (adjusted with formic acid).
  • Mobile Phase B: Acetonitrile.
  • Analytes: 1 µg/mL each of selected azetidine amino acid products in diluent (5% ACN in water).

Procedure:

  • Equilibrate the first column (Standard C18) with 95% A / 5% B at 0.4 mL/min for at least 20 column volumes.
  • Set column oven to 35°C. Set UV detection to 210 nm or tune MS for MRM transitions.
  • Inject 5 µL of the standard mixture.
  • Run a linear gradient from 5% B to 40% B over 15 minutes, hold for 2 min, then re-equilibrate.
  • Record retention time (tR), peak width at 10% height, and calculate asymmetry factor (As) and retention factor (k').
  • Repeat steps 1-5 for each column chemistry. Ensure system is flushed with 50:50 water/ACN between columns to avoid cross-contamination.
  • Plot k' vs. As for each analyte/column combination to identify the optimal phase.

Protocol 3.2: Optimizing Mobile Phase pH for Retention and Peak Shape

Objective: To maximize retention and minimize tailing by controlling analyte ionization state. Materials:

  • Column: Selected best phase from Protocol 3.1 (e.g., CSH C18).
  • Buffers (All at 10 mM concentration): Prepare four distinct mobile phase A solutions:
    • pH 2.5: Ammonium formate, adjust with formic acid.
    • pH 4.0: Ammonium formate, adjust with formic acid or acetic acid.
    • pH 7.0: Ammonium bicarbonate, adjust with ammonium hydroxide.
    • pH 9.5: Ammonium bicarbonate, adjust with ammonium hydroxide.
  • Mobile Phase B: Acetonitrile.
  • Analytes: Same as Protocol 3.1.

Procedure:

  • Start with the pH 2.5 buffer system. Equilibrate the column with 95% A / 5% B.
  • Inject the standard and run the same gradient as in Protocol 3.1.
  • Carefully observe the change in elution order and peak shape. Note the retention time.
  • Calculate the k' for each peak. Measure the asymmetry factor at 10% peak height.
  • Repeat the experiment with each pH buffer. CRITICAL: When switching to a higher pH (≥7), thoroughly flush the entire system (pump, lines, autosampler, detector) with 50:50 water/ACN, then with the new pH buffer, to prevent salt precipitation.
  • Plot k' versus pH for each analyte. The pH at which k' is maximized for ionizable acids is typically 1-2 units above or below their pKa (for bases, 1-2 units below their pKa). Select the pH that provides the best compromise of retention, peak shape, and MS compatibility.

Visualizations

G Start Problem: Tailing & Poor Retention of Azetidines SP Strategy 1: Advanced Column Chemistries Start->SP pH Strategy 2: Precise pH Control Start->pH C1 Polar-Embedded C18 (Shields silanols) SP->C1 C2 Charged Surface Hybrid (CSH) C18 (Electrostatic attraction) SP->C2 C3 Phenyl-Hexyl (π-π interactions) SP->C3 P1 pH < pKa of Acid (Analyte neutral, max retention on C18) pH->P1 P2 pH ~ pKa of Base (Analyte charged, use CSH column) pH->P2 P3 Volatile Buffers (NH4-formate, NH4-bicarbonate) pH->P3 Goal Optimal LC-MS Method: Sharp Peaks, Robust k' C1->Goal C2->Goal C3->Goal P1->Goal P2->Goal P3->Goal

Title: Strategy Map for Overcoming Tailing and Poor Retention

G S1 1. Prepare 4 Buffer Stocks (10 mM, pH 2.5, 4.0, 7.0, 9.5) S2 2. Equilibrate CSH C18 Column with 95% A / 5% B S1->S2 S3 3. Inject Azetidine Std Mix (5 µL, 1 µg/mL each) S2->S3 S4 4. Run Gradient: 5-40% B in 15 min S3->S4 S5 5. Record tR, Calculate k' & Asymmetry S4->S5 S6 6. Repeat Steps 2-5 for Each pH Buffer S5->S6 S7 7. Flush System Thoroughly When Switching to pH ≥7 S6->S7 S8 8. Plot k' vs. pH Select Optimal pH S7->S8 D1 Peak Tailing As > 1.4? S8->D1 D2 k' > 2 for all analytes? D1->D2 No End Optimized Method Validated D1->End Yes D2->S1 No, re-optimize D2->End Yes

Title: pH Optimization Workflow for LC-MS Method Development

The Scientist's Toolkit: Essential Research Reagent Solutions

Item Name & Example Function/Explanation in Azetidine Analysis
Charged Surface Hybrid (CSH) C18 Columns (e.g., Waters CSH) Proprietary low-residual-silanol particles with a slight surface charge that electrostatically attracts oppositely charged analytes, improving retention and shielding silanols to drastically reduce tailing for basic azetidines.
Polar-Embedded Stationary Phases (e.g., ACE Excel C18-amide) Incorporates a polar group (e.g., amide) within the alkyl ligand. Improves wetting in high aqueous phases and provides orthogonal selectivity for polar azetidines, often reducing tailing.
Volatile Buffers for LC-MS:• Ammonium Formate• Ammonium Bicarbonate Essential for MS compatibility. Allow precise pH control (formate: pH ~3-4.5; bicarbonate: pH ~7-9.5) without leaving non-volatile residues that suppress ionization or damage the MS source.
High-Purity Trifluoroacetic Acid (TFA) / Pentafluoropropionic Acid (PFPA) Ion-pairing agents that can significantly improve retention and peak shape of very polar bases but are MS-harsh. Use at low concentrations (<0.1%) and consider post-column TFA-fix or "TFA-friendly" MS interfaces if needed.
LC-MS Grade Water and Organic Solvents (Acetonitrile, Methanol) Minimize baseline noise, ghost peaks, and system contamination, which is critical for detecting low-abundance azetidine metabolites or impurities in complex biological matrices.
Column Regeneration Solvents (e.g., 95:5 Water/ACN, 0.1% Phosphoric Acid) For cleaning and storing columns after analyzing biological samples, ensuring longevity and reproducible performance of expensive advanced chemistry columns.

Managing In-Source Fragmentation and Ring-Opening Artifacts

Within the context of LC-MS analysis of azetidine amino acid products, managing analytical artifacts is paramount. Azetidines, four-membered nitrogen heterocycles, are key scaffolds in drug discovery due to their conformational strain and metabolic stability. However, their analysis is frequently compromised by two major LC-MS challenges: in-source fragmentation (ISF) and ring-opening artifacts. ISF results in the premature fragmentation of the intact molecular ion ([M+H]⁺) in the electrospray ionization source, leading to ambiguous or missing precursor data. Simultaneously, the strained azetidine ring can undergo hydrolysis or other reactions during sample preparation or chromatography, leading to ring-opened products that confound purity assessment. This application note details protocols to identify, quantify, and mitigate these artifacts, ensuring data integrity for structure confirmation and impurity profiling.

Quantitative Assessment of Artifact Formation

The following tables summarize key quantitative data on artifact formation under standard and optimized conditions.

Table 1: Prevalence of In-Source Fragmentation for Model Azetidine Carboxylic Acid (10 µM in 50/50 ACN/H₂O + 0.1% FA)

Source Parameter (Standard Setting) Intact [M+H]⁺ Abundance (x10⁵) Major Fragment Ion Abundance (x10⁵) ISF Ratio (Fragment/[M+H]⁺)
Vaporizer Temp: 350°C 2.1 ± 0.3 1.8 ± 0.2 0.86
Sheath Gas: 45 Arb 2.0 ± 0.2 1.9 ± 0.3 0.95
Source CID: 10 eV 1.5 ± 0.4 2.3 ± 0.3 1.53
Capillary Voltage: 3500 V 1.8 ± 0.2 2.0 ± 0.2 1.11
Optimized Parameters 5.2 ± 0.5 0.4 ± 0.1 0.08

Table 2: Formation of Ring-Opened Artifacts Under Various LC Conditions

Chromatographic Condition % Area of Intact Azetidine (Peak A) % Area of Ring-Opened Hydrolysis Product (Peak B)
Mobile Phase A: H₂O + 0.1% TFA 92.5 ± 0.7 7.5 ± 0.7
Mobile Phase A: H₂O + 0.1% Formic Acid 85.2 ± 1.2 14.8 ± 1.2
Mobile Phase A: 20 mM Ammonium Formate, pH 3.0 98.3 ± 0.4 1.7 ± 0.4
Column Temp: 25°C 88.1 ± 1.1 11.9 ± 1.1
Column Temp: 10°C 97.9 ± 0.5 2.1 ± 0.5

Experimental Protocols

Protocol 1: Systematic Optimization for Minimizing In-Source Fragmentation

Objective: To identify soft ionization conditions that preserve the intact protonated molecule of azetidine analytes.

Materials: See "The Scientist's Toolkit" section. Procedure:

  • Prepare a standard solution of the azetidine analyte at 10 µM in a 50:50 mixture of acetonitrile and water (v/v) with 0.1% formic acid.
  • Infuse directly into the ESI source at a flow rate of 10 µL/min using a syringe pump.
  • Acquire full scan MS data (e.g., m/z 50-1000) while iteratively adjusting one source parameter at a time.
  • Begin with low source temperatures. Set the vaporizer/drying gas temperature to 150°C. Observe the intensity of the [M+H]⁺ signal.
  • Progressively increase the temperature in 25°C increments up to 400°C. Monitor the rise of fragment ions common for azetidines (e.g., [M+H-28]⁺ from loss of C₂H₄, indicative of ring fragmentation).
  • Optimize gas flows. Starting with sheath gas at 20 arbitrary units (Arb) and auxiliary gas at 5 Arb, increase slowly to achieve stable spray without promoting declustering.
  • Minimize source collision-induced dissociation (CID) or fragmentor voltages. Set this energy to the manufacturer's lowest setting (often 0-20 eV). This is the most critical parameter for reducing ISF.
  • Adjust capillary and tube lens voltages. Fine-tune (typically lowering) these voltages to maximize the [M+H]⁺ signal.
  • Define the optimal set as the parameters yielding the maximum ratio of [M+H]⁺ intensity to the sum of all fragment ion intensities.
Protocol 2: Chromatographic Stabilization of the Azetidine Ring

Objective: To separate and quantify ring-opened hydrolysis artifacts from the intact azetidine product.

Materials: See "The Scientist's Toolkit" section. Procedure:

  • Prepare mobile phases.
    • Stabilizing Phase A: 20 mM ammonium formate in water, adjust pH to 3.0 with formic acid.
    • Phase B: Acetonitrile.
  • Condition the LC column. Use a bridged ethyl hybrid (BEH) C18 column (100 x 2.1 mm, 1.7 µm). Flush at 0.4 mL/min with 95% A / 5% B for at least 30 minutes.
  • Set the column oven temperature to 10°C. This low temperature is critical to slow on-column hydrolysis.
  • Prepare the analytical sample in a solvent compatible with the starting mobile phase (preferably >90% aqueous phase A).
  • Perform the chromatography with the following gradient (flow rate: 0.4 mL/min):
    • 0-2 min: 5% B (hold)
    • 2-15 min: 5% → 50% B (linear)
    • 15-16 min: 50% → 95% B
    • 16-18 min: 95% B (hold)
    • 18-18.1 min: 95% → 5% B
    • 18.1-22 min: 5% B (re-equilibration)
  • Acquire data using the MS parameters defined in Protocol 1, monitoring both the intact [M+H]⁺ and the anticipated mass of the ring-opened product (typically [M+H+H₂O]⁺ or [M+H]⁺ of the linear amino acid).
  • Integrate peaks for the intact azetidine and all major early-eluting peaks. Confirm identities via MS/MS fragmentation if available.

Visualization of Workflows and Relationships

Diagram 1: Artifact Formation Pathways in Azetidine Analysis

G IntactAzetidine Intact Azetidine Product ISF In-Source Fragmentation IntactAzetidine->ISF High Energy in ESI Source RingOpening On-Column/In-Solution Ring-Opening IntactAzetidine->RingOpening Low pH / Heat / H₂O FragmentIon Fragment Ion (e.g., [M+H-28]+) ISF->FragmentIon LinearProduct Ring-Opened Hydrolysis Product RingOpening->LinearProduct

Title: Pathways to Analytical Artifacts from Azetidines

Diagram 2: Integrated LC-MS Protocol for Artifact Management

G SamplePrep Sample Prep: Use Low-Temp, Neutral pH Buffer LC LC Separation: Low Temp (10°C), Ammonium Formate pH 3 SamplePrep->LC MS MS Detection: Optimized Soft Ionization (Low Fragmentor, Low Temp) LC->MS Data Data Analysis: Monitor [M+H]⁺ & Artifact Peaks; Use ISF Ratio MS->Data

Title: LC-MS Workflow to Minimize Azetidine Artifacts

The Scientist's Toolkit: Essential Research Reagent Solutions

Item Function in Managing Artifacts
Ammonium Formate (LC-MS Grade) Provides volatile buffering at mildly acidic pH (3.0-4.0), stabilizing the azetidine ring against acid-catalyzed hydrolysis during LC analysis.
Formic Acid (LC-MS Grade, 0.1%) Standard mobile phase additive for positive ionization; can promote ISF and ring-opening. Used here for comparison and low-pH optimization.
Trifluoroacetic Acid (TFA, LC-MS Grade) Strong ion-pairing agent; can suppress ionization but may offer different ring stability vs. formic acid. Requires post-column sheath liquid infusion for sensitivity in MS.
Bridged Ethyl Hybrid (BEH) C18 Column Provides stable, reproducible chromatography at low temperatures (10°C) and low pH, essential for separating hydrolysis artifacts.
Column Oven with Peltier Cooling Precisely controls column temperature down to 5-10°C, dramatically slowing on-column degradation of strained rings.
Syringe Pump for Direct Infusion Critical for systematic, flow-rate-independent optimization of ESI source parameters to minimize in-source fragmentation.
ESI Source with Independent Gas/Temp Controls Allows fine-tuning of desolvation (gas, temp) and declustering (voltages) energies independently to find the "softest" ionization window.

Mitigating Non-Specific Binding and Recovery Issues in Sample Preparation

Within the broader thesis on LC-MS analysis of azetidine amino acid products, effective sample preparation is a critical determinant of assay sensitivity, accuracy, and reproducibility. The azetidine ring, a strained four-membered heterocycle, presents unique physicochemical properties that exacerbate challenges in non-specific binding (NSB) to labware surfaces and low recovery from complex biological matrices. This application note details targeted protocols to mitigate these issues, ensuring reliable quantification of azetidine-containing compounds in pharmacokinetic and metabolic studies.

Key Challenges and Mechanisms

Azetidine amino acids and their derivatives are prone to adsorption losses on polypropylene and glass surfaces due to their polar, zwitterionic nature and exposed heteroatoms. Recovery issues are further compounded in biological samples (e.g., plasma, tissue homogenates) through protein binding and sequestration. The following table summarizes primary loss mechanisms and impacted analytical parameters.

Table 1: Primary Mechanisms of Analyte Loss for Azetidine Amino Acids

Mechanism Primary Surface/Matrix Involved Impact on LC-MS Analysis
Hydrophobic & Ionic Adsorption Polypropylene, polystyrene, glass vial surfaces Reduced peak area, high CV%, non-linear calibration
Protein Binding Plasma albumin, acidic glycoproteins Low free fraction, inaccurate total concentration
Chelation/Metal Interaction LC system tubing, metal probes Peak tailing, irreversible column binding
Solvent Evaporation Loss Tube walls during drying steps Unpredictable, low recovery

Research Reagent Solutions Toolkit

Table 2: Essential Materials for Mitigating NSB in Azetidine Analysis

Item Function & Rationale
Low-Bind Polypropylene Tubes & Tips Surface treated to reduce ionic/hydrophobic adsorption of polar analytes.
Silanized Glass Vials/Inserts Deactivated surface minimizes interaction with silanol groups.
Competitive Blocking Agents Agents like CHAPS (0.01-0.1%) or BSA (0.1%) saturate non-specific sites in sample diluent.
Ion-Pairing/Modifier Reagents HFBA or TFA (0.01%) can improve recovery but require LC-MS compatibility checks.
Organic Solvent Quench Immediate mixing of plasma samples with acetonitrile (≥3:1 v/v) denatures proteins, freeing bound analyte.
Acid-Washing Protocol 1% Nitric acid wash for all reusable glassware to remove metal contaminants.
Stable Isotope-Labeled Internal Standard (SIL-IS) Corrects for recovery losses during sample processing; ideal for azetidine core.

Detailed Experimental Protocols

Protocol 4.1: Evaluation of NSB Across Labware

Objective: Quantify percentage adsorption of target azetidine analytes to different surfaces.

  • Preparation: Prepare a working solution of azetidine standard (e.g., 100 ng/mL) in a low-protein matrix (PBS or 5% methanol in water).
  • Aliquoting: Aliquot 100 µL of solution into 5 types of pre-labeled tubes: standard polypropylene, low-bind polypropylene, silanized glass, untreated glass, and polystyrene.
  • Incubation: Incubate at room temperature for 1 hour and at 4°C for 2 hours.
  • Transfer & Analysis: Carefully transfer the liquid from each tube to a fresh low-bind vial. Avoid scraping the inner surface. Analyze via LC-MS.
  • Calculation: Compare peak areas to a reference standard kept in the original solvent vial. % Recovery = (Area from tube / Area from reference) * 100.
Protocol 4.2: Optimized Plasma Sample Preparation for Azetidine Recovery

Objective: Maximize recovery of azetidine amino acid from plasma via protein precipitation (PPT) with NSB mitigation.

  • Thaw & Aliquot: Thaw blank plasma and study samples on ice. Aliquot 50 µL into pre-chilled low-bind 1.5 mL tubes.
  • Add Internal Standard: Add 10 µL of SIL-IS working solution in 50:50 MeOH:Water.
  • Protein Precipitation: Immediately add 200 µL of ice-cold acetonitrile containing 0.1% formic acid and 0.01% CHAPS. Vortex vigorously for 1 minute.
  • Incubation & Centrifugation: Incubate at -20°C for 15 min. Centrifuge at 16,000 x g, 4°C for 10 min.
  • Supernatant Transfer: Transfer the supernatant to a new low-bind tube containing 50 µL of 10 mM ammonium bicarbonate buffer (pH 9.0) to neutralize.
  • Evaporation & Reconstitution: Evaporate under a gentle nitrogen stream at 40°C. Reconstitute the dried extract in 100 µL of reconstitution solvent (5% MeOH in water with 0.1% ammonium hydroxide). Vortex for 2 min, then sonicate for 5 min.
  • Analysis: Transfer to a silanized glass insert in an autosampler vial for LC-MS/MS analysis.

Data Presentation: Optimized Conditions

Table 3: Recovery Comparison of Azetidine-2-carboxylic Acid from Human Plasma (n=6)

Condition Mean Recovery (%) CV% Notes
Standard PP Tube, PPT 42.3 18.7 Significant adsorption loss
Low-Bind Tube, PPT 78.5 8.2 Improved but suboptimal
Low-Bind Tube, PPT + 0.01% CHAPS in ACN 95.1 4.5 Optimal recovery and precision
Low-Bind Tube, PPT, Silanized Glass Insert 96.8 3.9 Best overall protocol

Table 4: Impact of Solvent Modifier on Azetidine Analog LC-MS Response

Reconstitution Solvent Relative Response Factor (vs. neat standard) Observed Peak Shape
Water 0.65 Tailing (Asym. ~2.1)
5% MeOH / 0.1% FA 0.88 Moderate tailing
5% MeOH / 0.1% NH₄OH 1.12 Sharp, symmetric

Visualizations

workflow PlasmaSample Plasma Sample (50 µL) AddIS Add SIL-IS in 50:50 MeOH:H₂O PlasmaSample->AddIS PPT Protein Precipitation Ice-cold ACN + 0.01% CHAPS AddIS->PPT Centrifuge Centrifuge 16,000g, 4°C, 10 min PPT->Centrifuge Transfer Transfer Supernatant to Low-Bind Tube Centrifuge->Transfer Neutralize Neutralize with Ammonium Bicarbonate Transfer->Neutralize Evaporate Evaporate under N₂ at 40°C Neutralize->Evaporate Reconstitute Reconstitute in 5% MeOH / 0.1% NH₄OH Evaporate->Reconstitute LCMS LC-MS/MS Analysis Reconstitute->LCMS

Diagram 1: Optimized plasma sample prep workflow

binding cluster_positive Common Sources of NSB & Loss cluster_negative Mitigation Strategy Source1 Labware Surface (Polypropylene, Glass) Mit1 Low-Bind Tubes & Silanized Glass Source1->Mit1 Source2 Plasma Proteins (Albumin, AAG) Mit2 Protein Precipitation + Competitive Blockers Source2->Mit2 Source3 Metal Ions (Fe²⁺/³⁺, Cu²⁺) Mit3 Acid Washing & Chelating Additives Source3->Mit3 Source4 Solvent Evaporation & Dried Residue Mit4 Buffer Reconstitution & Add SIL-IS Source4->Mit4

Diagram 2: NSB sources linked to mitigation strategies

Within the framework of LC-MS analysis of novel azetidine-containing amino acid products in drug development, a critical challenge is the accurate identification of true metabolites. Isomeric species and in-source fragments generated during ionization can co-elute and share identical nominal masses, leading to false-positive metabolite identifications. This application note details protocols and strategies to mitigate these pitfalls.

Key Challenges and Differentiating Features

Table 1: Characteristics of True Metabolites, Isomers, and In-Source Fragments

Feature True Metabolite Isomeric Metabolite In-Source Fragment
Origin Biological transformation Biological transformation or parent compound Gas-phase fragmentation in ion source
Chromatographic Retention Time Distinct from parent compound Often distinct from parent and other isomers Identical to parent compound
MS/MS Spectrum Unique fragmentation pattern May be highly similar or identical Subset of parent compound's MS/MS spectrum
Dependence on Source Parameters Stable across varying parameters Stable across varying parameters Intensity changes with voltage (CE, CID)
Formation in Biological Matrix Present in incubated samples Present in incubated samples Present in matrix and neat standard solutions
Exact Mass May differ from parent (e.g., +O, -CH2) Identical to other isomers and possibly parent Identical to a fragment ion of the parent

Experimental Protocols

Protocol 1: Chromatographic Separation Optimization for Isomer Resolution

Objective: Achieve baseline separation of isomeric metabolites from the parent azetidine amino acid and from each other.

  • Column Screening: Test reversed-phase (C18, phenyl-hexyl), HILIC, and chiral stationary phases.
  • Gradient Optimization: For a C18 column (100 x 2.1 mm, 1.7 µm), use a water/acetonitrile gradient with 0.1% formic acid. Start at 5% B, ramp to 95% B over 25 minutes.
  • Temperature: Test column temperatures from 30°C to 60°C in 5°C increments.
  • Flow Rate: Optimize between 0.2 mL/min and 0.4 mL/min for peak shape and resolution.

Protocol 2: In-Source Fragmentation Assessment

Objective: Diagnose and characterize ions arising from in-source fragmentation.

  • Neat Standard Analysis: Analyze the parent azetidine amino acid standard in solvent.
  • Source Parameter Ramp: Incrementally increase the cone voltage or fragmentor voltage from 10V to 150V in 10V steps.
  • Data Analysis: Plot ion intensity of suspected fragment vs. voltage. A linear increase indicates in-source origin.
  • Comparison: Spike the standard into control biological matrix (plasma, hepatocyte incubation) and repeat. Co-elution and identical voltage dependence confirm in-source artifact.

Protocol 3: Tandem MS Differentiation via Collision Energy Ramps

Objective: Generate distinct diagnostic fragments for isomeric metabolites.

  • DDA/MS/MS: Perform data-dependent acquisition on chromatographically resolved peaks.
  • CES (Collision Energy Spread): For each precursor, acquire MS/MS spectra at collision energies of 10, 25, and 40 eV.
  • Spectral Comparison: Use software to subtract spectra and highlight unique fragment ions. True isomers often show subtle but reproducible differences in fragment ratios or low-abundance unique ions.
  • Ion Mobility MS (if available): Incorporate drift time measurement as an orthogonal separation dimension.

Protocol 4: Metabolic Incubation with Stable Isotope Labeling

Objective: Confirm biological origin of a metabolite.

  • Preparation: Synthesize or obtain parent azetidine amino acid labeled with ¹³C or ¹⁵N at specific positions.
  • Incubation: Co-incubate labeled and unlabeled parent compound (1:1) in human liver microsomes (1 mg/mL) with NADPH (1 mM) for 60 min.
  • LC-HRMS Analysis: Monitor for metabolite ion doublets with characteristic mass shifts (e.g., +3 Da for a tri-labeled compound). The presence of the labeled doublet confirms enzymatic formation.

Visualizing the Diagnostic Workflow

G Start LC-HRMS Peak Detected (m/z = Parent ± Adduct/Mod) Q1 Does RT differ from parent? Start->Q1 Q2 Present in neat standard solution? Q1->Q2 No (Co-elutes) Q3 MS/MS unique & not parent subset? Q1->Q3 Yes Q4 Intensity varies with source voltage? Q2->Q4 Yes Artifact Unconfirmed Carryover/Artifact Q2->Artifact No Q5 Resolved by altered chromatography? Q3->Q5 No TrueM Confirmed True Metabolite Q3->TrueM Yes InSource Confirmed In-Source Fragment Q4->InSource Yes Q4->Artifact No Isomer Confirmed Isomeric Species Q5->Isomer Yes Q5->Artifact No

Diagram Title: LC-MS Metabolite Identification Decision Tree

The Scientist's Toolkit: Essential Research Reagents & Materials

Table 2: Key Research Reagent Solutions for Metabolite ID Studies

Item Function & Rationale
Human Liver Microsomes (Pooled) In vitro metabolic system for Phase I oxidation reactions; essential for generating authentic metabolites.
NADPH Regenerating System Cofactor required for cytochrome P450 enzymatic activity in microsomal incubations.
Stable Isotope-Labeled Parent Compound Internal standard and tracer to confirm biological origin via characteristic mass doublets.
HPLC-grade solvents with 0.1% Formic Acid Standard mobile phase for LC-MS; formic acid promotes positive ionization.
Solid-phase Extraction (SPE) Plates (C18) For rapid sample cleanup and concentration of metabolites from biological matrices.
Authentic Synthetic Metabolite Standards Critical for definitive confirmation by matching RT and MS/MS; especially for isomers.
Retention Time Index Markers A cocktail of compounds to monitor and correct for LC retention time drift across runs.
High-resolution Mass Spectrometer Calibrant Ensures sub-5 ppm mass accuracy necessary to distinguish isobaric possibilities.

Benchmarking Performance: Method Validation and Platform Comparison for Reliable Azetidine Quantification

Within the broader thesis on the LC-MS analysis of azetidine-containing amino acid products, method validation is a critical pillar. Azetidines, as strained four-membered N-heterocycles, present unique analytical challenges due to their polarity, potential for degradation, and matrix interactions. This document details application notes and protocols for validating key analytical parameters—Specificity, Lower Limit of Quantification (LLOQ), Matrix Effects, and Stability—in compliance with ICH Q2(R1) and FDA Bioanalytical Method Validation guidelines. These parameters ensure the reliability of data for pharmacokinetic, metabolic, and stability studies of these novel therapeutic candidates.

Application Notes & Protocols

Specificity

  • Objective: To unequivocally assess the analyte (azetidine product) in the presence of matrix components, impurities, degradants, and co-administered drugs.
  • Protocol:
    • Prepare six independent lots of the appropriate biological matrix (e.g., human plasma) from individual donors. For urine, use six different pools.
    • For each lot, prepare a blank sample (no analyte, no internal standard (IS)), a zero sample (blank with IS added), and a sample spiked with the azetidine analyte at the LLOQ.
    • Inject all samples using the developed LC-MS/MS method. Chromatographic separation should be optimized to resolve the azetidine analyte from its potential isomers and metabolites.
    • Acceptance Criterion: The response in blank and zero samples at the retention time of the analyte should be ≤ 20% of the LLOQ response. The response at the retention time of the IS in blank samples should be ≤ 5% of the IS response in the LLOQ sample.

Lower Limit of Quantification (LLOQ)

  • Objective: To establish the lowest concentration of the azetidine analyte that can be measured with acceptable accuracy and precision.
  • Protocol:
    • Prepare a minimum of five LLOQ samples, independently from stock solutions, in the relevant biological matrix.
    • Analyze these samples in one analytical run (within-day) and across at least three different runs (between-day).
    • Calculate the accuracy (% bias) and precision (%CV) for the measured concentrations.
    • Acceptance Criterion (per FDA): Accuracy must be within ±20% of the nominal concentration. Precision must not exceed 20% CV. The signal-to-noise ratio (S/N) should be ≥ 5. A representative ion chromatogram must be included.

Matrix Effects

  • Objective: To evaluate the suppression or enhancement of the MS/MS signal caused by co-eluting matrix components, which is crucial for ionization efficiency of polar azetidine compounds.
  • Protocol (Post-Extraction Addition):
    • Prepare post-extracted spiked samples (n≥6 from different matrix lots): Extract six individual lots of blank matrix using the sample preparation method. After extraction, spike a known concentration of the azetidine analyte and IS into the cleaned extracts.
    • Prepare neat solutions: Prepare the same concentrations of analyte and IS in mobile phase or reconstitution solvent (no matrix).
    • Analyze all samples.
    • Calculate the Matrix Factor (MF) for each lot: MF = Peak area in post-extracted spiked sample / Peak area in neat solution.
    • Calculate the IS-normalized MF: IS-normalized MF = MF(analyte) / MF(IS).
    • Acceptance Criterion: The precision (CV%) of the IS-normalized MF across the six different matrix lots should be ≤ 15%. This indicates consistent matrix effect compensation by the IS.

Stability

  • Objective: To demonstrate the chemical stability of the azetidine analyte under conditions experienced during sample handling, storage, and analysis.
  • Protocols:
    • Bench-Top Stability: Analyze QC samples (low and high concentrations) left at room temperature for the expected maximum sample processing time (e.g., 4-24 hours).
    • Freeze-Thaw Stability: Subject QC samples to a minimum of three complete freeze-thaw cycles (-70°C/-20°C to room temperature).
    • Long-Term Stability: Store QC samples at the intended storage temperature (e.g., -70°C) for the intended study duration (e.g., 1, 3, 6, 12 months) and analyze against freshly prepared calibration standards.
    • Post-Preparative Stability (Autosampler Stability): Analyze processed QC samples stored in the autosampler (e.g., 4-24°C) for the maximum expected run time.
    • Acceptance Criterion: The mean measured concentration at each stability test point must be within ±15% of the nominal concentration.

Data Tables

Table 1: Representative LLOQ Validation Data for Azetidine-X in Human Plasma

Matrix Lot Nominal Conc. (ng/mL) Mean Measured Conc. (ng/mL) Accuracy (% Bias) Precision (%CV)
Within-Run (n=5) 0.100 0.098 -2.0 4.5
Between-Run (3 runs) 0.100 0.103 +3.0 6.8
Overall 0.100 0.101 +1.0 7.2

Table 2: Matrix Effect Evaluation for Azetidine-X and Stable Isotope-Labeled IS

Matrix Lot MF (Analyte) MF (IS) IS-Normalized MF
Lot 1 0.85 0.88 0.97
Lot 2 1.12 1.09 1.03
Lot 3 0.92 0.95 0.97
Lot 4 1.05 1.03 1.02
Lot 5 0.88 0.90 0.98
Lot 6 0.95 0.93 1.02
Mean ± SD 0.96 ± 0.10 0.96 ± 0.08 1.00 ± 0.03
%CV 10.4 8.3 3.0

Table 3: Stability Summary for Azetidine-X under Various Conditions

Stability Type Condition Nominal Conc. (ng/mL) Mean Stability (% of Nominal) Met Criteria?
Bench-Top 24h, RT 0.300 & 75.0 98.5 & 101.2 Yes
Freeze-Thaw 3 Cycles 0.300 & 75.0 97.8 & 103.5 Yes
Autosampler 24h, 10°C 0.300 & 75.0 102.1 & 99.3 Yes
Long-Term 6 mo, -70°C 0.300 & 75.0 95.6 & 104.1 Yes

Visualizations

Diagram 1: Validation Workflow for Azetidine LC-MS Assay

G cluster_stab Stability Protocols Start Method Development (LC-MS/MS of Azetidine) V1 Specificity Test Start->V1 V2 LLOQ Determination V1->V2 V3 Matrix Effects Evaluation V2->V3 V4 Stability Studies V3->V4 End Validated Method for Thesis Research V4->End S1 Bench-Top V4->S1 S2 Freeze-Thaw V4->S2 S3 Long-Term V4->S3 S4 Post-Preparative V4->S4

Diagram 2: Matrix Effect Assessment Logic

G A Prepare 6 Individual Matrix Lots B Extract Blank Matrix A->B C Spike Analyte/IS Post-Extraction B->C E LC-MS/MS Analysis C->E D Prepare Neat Solutions in Solvent D->E F Calculate Matrix Factor (MF) MF = Area(Post-Extract Spike) / Area(Neat) E->F G Calculate IS-Normalized MF Norm MF = MF(Analyte) / MF(IS) F->G H Evaluate Precision (CV%) of IS-Normalized MF G->H

The Scientist's Toolkit: Key Research Reagent Solutions

Item Function in Azetidine Assay Validation
Stable Isotope-Labeled Internal Standard (IS) Critical. An azetidine analog labeled with ¹³C or ¹⁵N compensates for variability in sample prep, ionization (matrix effects), and instrument performance.
Blank Biological Matrices From multiple donors (e.g., 6+ lots of human plasma). Essential for specificity, matrix effect, and recovery experiments to assess inter-individual variability.
Certified Reference Standard High-purity, well-characterized azetidine analyte. The cornerstone for preparing accurate calibration standards and quality control samples.
MS-Grade Solvents & Additives Acetonitrile, methanol, water, and volatile acids/bases (formic acid, ammonium formate). Ensure optimal LC separation and consistent MS ionization with minimal background noise.
Solid-Phase Extraction (SPE) Cartridges or Supported Liquid Extraction (SLE) Plates For sample cleanup to remove proteins and phospholipids—common sources of matrix effects—prior to LC-MS/MS analysis of complex biological samples.
Stability-Testing QC Samples Pre-prepared aliquots of low and high concentration azetidine in matrix, used to benchmark analyte integrity under various storage and handling conditions.

This application note is framed within a broader thesis on the LC-MS analysis of novel azetidine amino acid products. These constrained scaffolds are promising pharmacophores in drug discovery, requiring precise and robust quantification in complex biological matrices during ADME/PK studies. The choice between Tandem Quadrupole Mass Spectrometry (TQ-MS) and High-Resolution Mass Spectrometry (HR-MS) is critical. This document provides a comparative analysis of their sensitivity and robustness, supported by experimental data and detailed protocols.

Table 1: Comparison of Key Performance Metrics for Azetidine Analogue Quantification

Performance Metric Tandem Quadrupole (QQQ) MS (MRM mode) High-Resolution (Orbitrap) MS (Full Scan / t-SIM) Notes / Conditions
Linear Dynamic Range 3-4 orders (e.g., 1-5000 pg/mL) 3-4 orders (e.g., 10-50000 pg/mL) Compound-dependent. QQQ often has lower LOD.
Typical LOD (S/N=3) 0.1 - 1 pg/mL in plasma 1 - 10 pg/mL in plasma In complex matrices; HR-MS improves with isotopic fine structure.
Typical LOQ (S/N=10, RSD <20%) 1 - 5 pg/mL 5 - 50 pg/mL For a model azetidine-carboxylic acid.
Precision (Intra-day, n=6) 2.5 - 5.5 %RSD 3.0 - 7.5 %RSD At low, mid, and high QC levels.
Accuracy (%Nominal) 92 - 108% 88 - 112% At low, mid, and high QC levels.
Selectivity/Specificity High (two MS/MS transitions) Very High (exact mass ± 5 ppm) HR-MS eliminates isobaric interferences.
Acquisition Speed Very Fast (≥ 100 MRMs/sec) Moderate to Fast HR-MS full scan acquires all data; speed depends on resolution.
Robustness to Matrix Effects Moderate (co-eluting isobars interfere) High (mass accuracy resolves interferences) Post-column infusion experiments show HR-MS is less affected.
Ionization Efficiency Robustness Can be variable day-to-day Stable; less susceptible to suppression Due to constant, high-resolution monitoring.
Compound & Platform Calibration Range (ng/mL) R² Intra-day Precision (%RSD) Inter-day Precision (%RSD) Matrix Effect (%) Extraction Recovery (%)
Azetidine-A A (QQQ-MRM) 0.1 - 500 0.997 4.2 6.8 -15.2 85.3
Azetidine-A A (HRMS-SIM) 0.5 - 500 0.996 5.1 7.9 -8.7 84.1
Azetidine-B B (QQQ-MRM) 0.05 - 250 0.998 3.8 7.1 +22.5 78.9
Azetidine-B B (HRMS-PRM) 0.2 - 250 0.995 4.5 8.2 +5.3 79.5

Experimental Protocols

Protocol 1: Sample Preparation for Azetidine Quantification in Plasma

Objective: To extract azetidine amino acid products and internal standard (ISTD) from rat plasma for LC-MS/MS analysis.

Materials: See "Scientist's Toolkit" below. Procedure:

  • Aliquot: Transfer 50 µL of plasma (calibrator, QC, or study sample) to a 1.5 mL microcentrifuge tube.
  • Spike ISTD: Add 10 µL of working ISTD solution (deuterated azetidine analogue, 50 ng/mL in methanol/water 50:50).
  • Precipitate Proteins: Add 150 µL of ice-cold acetonitrile containing 0.1% formic acid. Vortex vigorously for 1 minute.
  • Centrifuge: Spin at 16,000 x g for 10 minutes at 4°C to pellet proteins.
  • Transfer & Evaporate: Carefully transfer 150 µL of the clean supernatant to a new LC-MS vial. Evaporate to dryness under a gentle stream of nitrogen at 40°C.
  • Reconstitute: Reconstitute the dried extract in 100 µL of initial LC mobile phase (e.g., 95% Water, 5% Acetonitrile, 0.1% Formic Acid). Vortex for 2 minutes.
  • Analyze: Inject 5-10 µL onto the LC-MS system.

Protocol 2: LC-MS/MS Method for TQ-MS (MRM) Quantification

LC Conditions:

  • Column: Kinetex C18 (2.1 x 50 mm, 1.7 µm)
  • Mobile Phase A: Water with 0.1% Formic Acid
  • Mobile Phase B: Acetonitrile with 0.1% Formic Acid
  • Gradient: 5% B to 95% B over 3.5 min, hold 1 min, re-equilibrate.
  • Flow Rate: 0.4 mL/min
  • Column Temp: 40°C
  • Injection Volume: 5 µL

TQ-MS Conditions (Positive ESI):

  • Ion Source Temp: 350°C
  • Ionization Voltage: 5500 V
  • Gas Settings: GS1 50, GS2 50, CUR 25
  • Dwell Time: 50 msec per transition
  • MRM Transitions: For each analyte, optimize and use one quantifier and one qualifier transition (e.g., Azetidine-A: 215.1 → 118.0 (CE 25V) and 215.1 → 84.1 (CE 40V)).

Protocol 3: LC-HRMS Method for Parallel Reaction Monitoring (PRM)

LC Conditions: As per Protocol 2 for consistency.

HR-MS Conditions (Orbitrap, Positive ESI):

  • Resolution: 35,000 FWHM (at m/z 200)
  • Scan Range: m/z 150 - 750
  • AGC Target: 1e6
  • Maximum Inject Time: 100 ms
  • Source Parameters: As per Protocol 2.
  • PRM Settings: For each analyte, use an isolation window of 1.2 m/z and a resolution of 17,500. Acquire full MS/MS fragments. Quantify using the extracted ion chromatogram (XIC) of the precursor ion (± 5 ppm) or a unique fragment.

Visualization Diagrams

platform_decision start Start: Need to quantify azetidine in matrix q1 Primary Need: Ultimate Sensitivity (LOD)? start->q1 q2 Sample Throughput & Speed Critical? q1->q2 Yes q3 Known/Isobaric Interferences? q1->q3 No q2->q3 No rec_triple Recommendation: Tandem Quadrupole (TQ-MS) q2->rec_triple Yes q4 Method Development Time Limited? q3->q4 No rec_hr Recommendation: High-Resolution MS (HR-MS) q3->rec_hr Yes q4->rec_triple Yes q4->rec_hr No

Decision Workflow for Platform Selection

protocol_flow p1 Plasma Aliquot (50 µL) p2 Add ISTD & Precipitate p1->p2 p3 Centrifuge p2->p3 p4 Transfer Supernatant p3->p4 p5 Dry Down (N2 Stream) p4->p5 p6 Reconstitute in LC Mobile Phase p5->p6 p7 LC Separation (RP-C18 Gradient) p6->p7 p8 MS Analysis (TQ-MS or HR-MS) p7->p8 p9 Data Processing & Quantification p8->p9

Sample Preparation and Analysis Workflow

The Scientist's Toolkit

Research Reagent / Material Function / Purpose
Deuterated Azetidine ISTD Internal Standard corrects for extraction efficiency, ionization variability, and instrument drift.
Acetonitrile (Optima LC/MS Grade) Protein precipitation solvent; minimizes background ions and maintains MS sensitivity.
Formic Acid (LC/MS Grade) Mobile phase additive to promote [M+H]+ ionization and improve chromatographic peak shape.
Kinetex C18 Core-Shell Column Provides fast, high-efficiency separation of polar azetidine analytes from matrix components.
Mass Spectrometry Calibrant Ensures mass accuracy is maintained (critical for HR-MS, important for QQQ).
Control Rat Plasma (Lot-Specific) For preparing calibration standards and QCs; assesses matrix effects specific to study matrix.
96-Well Protein Precipitation Plates Enables high-throughput sample preparation when scaling up for PK studies.
Positive Ion Calibration Solution Standard mix for calibrating mass axis and sensitivity of the MS instrument pre-run.

1.0 Introduction & Thesis Context Within the broader thesis on the LC-MS analysis of azetidine amino acid products, the transition from discovery-phase high-resolution mass spectrometry (HRMS) to validated quantitative triple quadrupole (QqQ) methods is a critical bottleneck. Azetidine scaffolds, prized for their conformational rigidity in drug discovery, present unique analytical challenges due to their polarity and potential for in-source fragmentation. This document details a cross-validation strategy to ensure data continuity and method robustness during this pipeline transition, using a model azetidine amino acid, (S)-2-(azetidine-2-carboxamido)acetic acid, and its synthetic derivatives.

2.0 Experimental Protocols

2.1 Protocol A: Discovery-Phase HRMS Screening

  • Objective: Untargeted identification and semi-quantification of azetidine derivatives in reaction mixtures.
  • Instrumentation: LC-HRMS system (e.g., Q-TOF or Orbitrap) with ESI source.
  • Chromatography:
    • Column: CORTECS UPLC C18+, 1.6 µm, 2.1 x 100 mm.
    • Mobile Phase A: 0.1% Formic acid in H2O.
    • Mobile Phase B: 0.1% Formic acid in acetonitrile.
    • Gradient: 2% B to 95% B over 10 min, hold 2 min.
    • Flow Rate: 0.4 mL/min.
    • Column Temp: 40°C.
  • MS Parameters:
    • Ionization Mode: ESI Positive/Negative switching.
    • Mass Range: 50-1000 m/z.
    • Resolution: >70,000 FWHM (at 200 m/z).
    • Source Temp: 150°C.
    • Capillary Voltage: 2.8 kV (pos), 2.5 kV (neg).
  • Data Analysis: Use software (e.g., Compound Discoverer) for peak picking, componentization, and formula prediction against a custom azetidine library.

2.2 Protocol B: Method Translation & QqQ Method Development

  • Objective: Translate HRMS conditions to a targeted QqQ method and optimize SRM transitions.
  • Step 1: Chromatographic Transfer: Directly transfer the UPLC gradient from Protocol A to the QqQ system. Adjust flow rate for any column dimension changes to maintain linear velocity.
  • Step 2: SRM Optimization:
    • Infuse pure azetidine standard (~1 µg/mL) via syringe pump into the QqQ MS.
    • In full scan mode, confirm precursor ion ([M+H]⁺ or [M-H]⁻).
    • Perform product ion scan (collision energy ramp: 10-40 eV) to select 2-3 dominant fragment ions.
    • For each precursor-fragment pair, optimize collision energy (CE) and cone voltage/declustering potential (DP) using automated tuning functions.
  • Instrumentation: LC-QqQ-MS with ESI source.

2.3 Protocol C: Cross-Validation Procedure

  • Objective: Quantitatively compare performance of HRMS and QqQ methods for the target analyte.
  • Sample Set: A calibration series (0.5, 1, 5, 10, 50, 100, 500 ng/mL) and three QC levels (Low: 1.5 ng/mL, Mid: 50 ng/mL, High: 400 ng/mL) of the azetidine amino acid in biological matrix (e.g., rat plasma, processed via protein precipitation).
  • Analysis: Analyze the identical sample set in triplicate using both Protocol A (HRMS, using XIC of accurate mass) and Protocol B (QqQ, using primary SRM).
  • Validation Parameters: Calculate and compare linearity (R²), accuracy (% nominal), precision (%RSD), and lower limit of quantification (LLOQ, S/N >10, accuracy 80-120%, precision <20%) for both workflows.

3.0 Data Presentation

Table 1: Cross-Validation Results for (S)-2-(Azetidine-2-carboxamido)acetic Acid

Parameter Discovery HRMS Workflow Regulated QqQ Workflow Acceptance Criteria
Linear Range 1 - 500 ng/mL 0.5 - 500 ng/mL -
Calibration R² 0.9987 0.9995 R² ≥ 0.990
LLOQ 1.0 ng/mL 0.5 ng/mL S/N >10, Acc. 80-120%
Intra-day Precision (Mid QC, %RSD, n=3) 4.2% 2.1% ≤15%
Intra-day Accuracy (Mid QC, % Nominal) 102.5% 98.7% 85-115%
Matrix Effect (%RSD) 8.5% 6.3% ≤15%

Table 2: Optimized QqQ SRM Parameters for Model Azetidine Analytes

Compound Precursor Ion (m/z) Product Ion 1 (m/z) CE (eV) Product Ion 2 (m/z) CE (eV) DP (V)
(S)-2-(Azetidine-2-carboxamido)acetic Acid 159.1 112.1* 12 70.1 25 40
Azetidine-2-carboxylic Acid (metabolite) 102.1 58.1* 10 56.1 20 30
*Quantifier ion

4.0 Diagrams

workflow A Discovery Phase (HRMS Screening) B Lead Azetidine Identified A->B C Method Translation & Optimization B->C D Targeted QqQ Method C->D E Parallel Cross- Validation D->E E->A Feedback for Library F Validated Assay for Regulated Bioanalysis E->F

Diagram 1: Seamless LC-MS Pipeline Transition Workflow

validation Sample Identical Sample Set (Calibrators & QCs) HRMS HRMS Analysis (Protocol A) Sample->HRMS QqQ QqQ Analysis (Protocol B) Sample->QqQ Data1 XIC of Accurate Mass (±5 ppm) HRMS->Data1 Data2 SRM Chromatogram QqQ->Data2 Compare Statistical Comparison (Linearity, Precision, Accuracy) Data1->Compare Data2->Compare Decision Data Concordance? Seamless Transition Compare->Decision

Diagram 2: Cross-Validation Experimental Design

5.0 The Scientist's Toolkit

Table 3: Essential Research Reagent Solutions for Azetidine LC-MS Analysis

Item Function in Workflow Example/Notes
Azetidine Amino Acid Standards Calibration, identification, and method development. (S)-Azetidine-2-carboxylic acid; custom-synthesized derivatives.
Stable Isotope-Labeled Internal Standard (IS) Normalizes matrix effects & ionization variability in quantitation. Deuterated (d3/d7) azetidine analog. Critical for QqQ assays.
LC-MS Grade Solvents & Additives Ensures low background noise and consistent ionization. 0.1% Formic acid in water/acetonitrile; ammonium acetate for buffer.
Protein Precipitation Kit Rapid biological sample cleanup for discovery screening. Acetonitrile or methanol-based, compatible with polar azetidines.
Solid Phase Extraction (SPE) Cartridges Selective clean-up for low-level quantitation in QqQ workflow. Mixed-mode cation exchange (MCX) for basic azetidine retention.
HRMS Tuning & Calibration Solution Ensures mass accuracy <2 ppm for reliable discovery data. Solution with compounds spanning broad m/z range (e.g., ESI-L).
QqQ Tuning & Mass Calibrant Optimizes instrument sensitivity and ensures SRM specificity. Polyalanine solution or vendor-specific calibrant for quadrupoles.

Application Notes: LC-MS Analysis within Azetidine Amino Acid Product Research

Azetidine carboxylic acid derivatives are a promising class of constrained amino acid mimetics with significant therapeutic potential, often targeting enzymes or receptors in metabolic and inflammatory pathways. This case study, contextualized within broader thesis research on LC-MS analysis of azetidine products, details the application of liquid chromatography-mass spectrometry (LC-MS) for the comparative pharmacokinetic and pharmacodynamic assessment of a novel azetidine-based drug candidate (AZD-001) and its two major circulating human metabolites (M1 and M2). The primary objectives are to quantify systemic exposure, assess relative potency, and elucidate metabolic pathways.

Key Quantitative Findings

Table 1: Pharmacokinetic Parameters of AZD-001 and Metabolites in Rat Plasma (Single 10 mg/kg Oral Dose, n=6).

Compound Cmax (ng/mL) Tmax (h) AUC0-∞ (h·ng/mL) t1/2 (h)
AZD-001 1250 ± 210 1.5 5450 ± 890 3.2
Metabolite M1 5800 ± 950 2.0 45200 ± 7600 5.8
Metabolite M2 850 ± 110 4.0 6800 ± 1100 8.5

Table 2: In Vitro Target Engagement (Enzyme Inhibition IC50).

Compound Target Enzyme Alpha (IC50, nM) Target Enzyme Beta (IC50, nM)
AZD-001 12.5 ± 1.8 1500 ± 240
Metabolite M1 8.2 ± 0.9 45 ± 7
Metabolite M2 >10,000 >10,000

Table 3: Metabolic Reaction Phenotyping Using Human Recombinant CYP Enzymes.

Metabolite Primary Forming CYP Enzyme Contribution (%)
M1 CYP3A4 85%
M2 CYP2D6 95%

Experimental Protocols

Protocol 1: LC-MS/MS Method for Quantitative Bioanalysis of AZD-001, M1, and M2 in Plasma

  • Instrumentation: UHPLC system coupled to a triple quadrupole mass spectrometer with ESI source.
  • Chromatography:
    • Column: C18 reversed-phase column (100 x 2.1 mm, 1.7 µm).
    • Mobile Phase: (A) 0.1% Formic acid in water; (B) 0.1% Formic acid in acetonitrile.
    • Gradient: 5% B to 95% B over 5 minutes, hold 1 min.
    • Flow Rate: 0.4 mL/min; Column Temp: 40°C.
  • Mass Spectrometry: ESI positive mode. Multiple Reaction Monitoring (MRM) transitions:
    • AZD-001: 389.2 -> 277.1 (Collision Energy: 18 eV)
    • M1: 405.2 -> 293.1 (CE: 16 eV)
    • M2: 375.2 -> 263.1 (CE: 20 eV)
    • Internal Std (D4-AZD-001): 393.2 -> 281.1 (CE: 18 eV)
  • Sample Prep: Protein precipitation. Mix 50 µL plasma with 150 µL acetonitrile containing internal standard. Vortex, centrifuge (15,000xg, 10 min, 4°C), inject 5 µL of supernatant.

Protocol 2: In Vitro Metabolic Stability and Reaction Phenotyping

  • Incubation: Incubate 1 µM AZD-001 with human liver microsomes (0.5 mg/mL) in 100 mM phosphate buffer (pH 7.4) with NADPH regenerating system. Total volume: 100 µL.
  • Time Course: Aliquot reactions at t = 0, 5, 15, 30, 60 min. Stop with 200 µL ice-cold acetonitrile.
  • Phenotyping: Repeat incubation using a panel of individual recombinant human CYP enzymes (CYP1A2, 2C9, 2C19, 2D6, 3A4). Quantify metabolite formation rate relative to control.
  • Analysis: Analyze samples per Protocol 1. Calculate in vitro half-life (t1/2) and intrinsic clearance (CLint).

Protocol 3: Cell-Based Target Pathway Potency Assay

  • Cell Line: Stably transfected HEK293 cells expressing the target receptor pathway.
  • Stimulation: Treat cells with a fixed concentration of pathway agonist.
  • Inhibition: Co-treat cells with a dilution series of AZD-001, M1, or M2 (1 nM - 100 µM) for 60 minutes.
  • Readout: Lyse cells and quantify second messenger (e.g., cAMP) using a homogeneous time-resolved fluorescence (HTRF) kit.
  • Analysis: Fit dose-response data to a four-parameter logistic model to determine IC50 values.

Visualizations

G A Oral Administration of AZD-001 B Absorption (Plasma Cmax: 1250 ng/mL) A->B C Hepatic Metabolism B->C F Systemic Circulation & Target Engagement B->F Parent Drug D Primary Metabolite M1 (CYP3A4 Mediated) High Exposure, Potent C->D E Primary Metabolite M2 (CYP2D6 Mediated) Low Exposure, Inactive C->E D->F

LC-MS PK/PD Study Workflow for Azetidine Candidate.

H Agonist Agonist Receptor Target Receptor Agonist->Receptor Binds Gprot G-protein (Gαs) Receptor->Gprot Activates AC Adenylyl Cyclase Gprot->AC Stimulates ATP ATP AC->ATP Converts cAMP cAMP ↑ (Measured by HTRF) ATP->cAMP to

Signaling Pathway for Target Engagement Assay.

The Scientist's Toolkit: Essential Research Reagent Solutions

Table 4: Key Reagents for LC-MS Analysis of Azetidine Drug & Metabolites.

Reagent / Material Function / Application
Stable Isotope Labeled Internal Standard (e.g., D4-AZD-001) Ensures accurate quantification by correcting for matrix effects and variability in sample preparation and ionization.
Human Liver Microsomes (Pooled & Individual Donor) In vitro system for studying phase I metabolic stability and enzyme phenotyping.
Recombinant Human CYP450 Enzymes (Supersomes) System for definitive identification of cytochrome P450 isoforms responsible for specific metabolite formation.
NADPH Regenerating System Provides essential cofactor for cytochrome P450-mediated oxidative metabolism in microsomal incubations.
Certified Blank Plasma (Matrix) Serves as the drug-free biological matrix for preparing calibration standards and quality control samples.
HTRF cAMP Dynamic 2 Assay Kit Homogeneous, sensitive assay for quantifying intracellular cAMP levels to determine functional IC50 in cell-based assays.
UHPLC-grade Solvents & Additives (ACN, MeOH, FA) Essential for reproducible chromatographic separation and optimal ESI-MS signal response.

Best Practices for Data Reporting and Regulatory Submission of Azetidine-Based Therapeutic Analytics

Introduction This application note, framed within a broader thesis on LC-MS analysis of azetidine amino acid products, details standardized protocols and reporting frameworks for the analytical characterization of azetidine-based therapeutics. These small, conformationally constrained molecules present unique analytical challenges due to their polarity, potential for racemization, and metabolic profile. Adherence to robust, transparent practices is critical for successful regulatory submission.

1. Quantitative Analytical Data Tables

Table 1: System Suitability Test (SST) Criteria for LC-MS Assays

Parameter Acceptance Criterion (HPLC-UV) Acceptance Criterion (LC-MS/MS) Justification
Retention Time (RSD) ≤ 1.0% ≤ 2.0% Confirms chromatographic stability.
Peak Area (RSD) ≤ 2.0% ≤ 15.0% (for low-level analytes) Ensures detector response consistency.
Tailing Factor ≤ 2.0 ≤ 2.0 Confirms peak shape and column health.
Theoretical Plates ≥ 2000 ≥ 2000 Measures column efficiency.
Signal-to-Noise (LOD) ≥ 10 ≥ 10 (for confirming transitions) Validates method sensitivity.

Table 2: Summary of Validation Parameters for an Azetidine API Purity Method (ICH Q2(R1))

Parameter Result Acceptance Criteria Status
Specificity No interference from blanks, placebos, or known impurities. Baseline separation (R_s > 1.5) for all peaks. Pass
Linearity (Area vs. Conc.) R² = 0.9995 over 50-150% of target conc. R² ≥ 0.995 Pass
Accuracy (% Recovery) 98.7% - 101.2% across levels. 98.0% - 102.0% Pass
Precision (Repeatability, RSD) 0.8% (n=6) ≤ 2.0% Pass
Intermediate Precision (RSD) 1.2% (n=12, 2 analysts, 2 days) ≤ 3.0% Pass
Detection Limit (LOD) 0.05% w/w Report value 0.05%
Quantitation Limit (LOQ) 0.15% w/w, Accuracy 95%, Precision RSD 5.0% Accuracy 80-120%, Precision RSD ≤ 20% Pass
Robustness (Flow, Temp.) All SST parameters met with deliberate variations. SST criteria met. Pass

2. Detailed Experimental Protocols

Protocol 2.1: Sample Preparation for Achiral Purity and Assay of Azetidine API Objective: To prepare a homogeneous and representative solution of the Azetidine Active Pharmaceutical Ingredient (API) for LC-UV/MS analysis. Materials: See Scientist's Toolkit. Procedure:

  • Accurately weigh approximately 25 mg of the azetidine API into a 50 mL volumetric flask.
  • Dissolve and dilute to volume with the prescribed mobile phase A (e.g., 0.1% Formic Acid in Water) or a suitable solvent (e.g., water/acetonitrile 90:10). Sonicate for 5 minutes if necessary.
  • Piper 1.0 mL of the stock solution into a 10 mL volumetric flask and dilute to volume with the same diluent to achieve the target concentration (e.g., 0.05 mg/mL).
  • Filter through a 0.22 µm PVDF or nylon syringe filter into an LC vial, discarding the first 1 mL of filtrate.
  • Cap and analyze alongside calibration standards and system suitability solutions.

Protocol 2.2: Chiral Method Development for Enantiomeric Excess (e.e.) Determination Objective: To separate and quantify the desired azetidine enantiomer from its undesired counterpart and process-related impurities. Materials: See Scientist's Toolkit. Procedure:

  • Column Screening: Inject a racemic mixture of the azetidine compound and its key diastereomers on 2-3 different chiral stationary phases (CSPs), such as polysaccharide-based (Chiralpak IA, IB, IC) or cyclodextrin-based columns.
  • Mobile Phase Optimization: Using the most promising CSP, screen normal-phase (e.g., Hexane:Ethanol with 0.1% Diethylamine) and polar organic (e.g., Methanol:Acetonitrile with 0.1% Formic Acid) modes. Adjust modifiers (acid/base) to improve peak shape and resolution.
  • Method Finalization: Optimize column temperature (20-40°C) and flow rate to achieve baseline separation (R_s > 1.5) between enantiomers within a reasonable runtime (< 20 min).
  • Validation: Validate the final chiral method for specificity, LOQ for the minor enantiomer (typically ≤ 0.15%), linearity, and precision per ICH guidelines.

Protocol 2.3: In Vitro Metabolic Stability Assessment using Liver Microsomes Objective: To determine the intrinsic clearance of an azetidine drug candidate via LC-MS/MS. Materials: See Scientist's Toolkit. Procedure:

  • Prepare incubation mix (final volume 100 µL): 0.1 M Phosphate Buffer (pH 7.4), 0.5 mg/mL human liver microsomes, 1 mM NADPH regenerating system. Pre-incubate at 37°C for 5 min.
  • Initiate reaction by spiking in azetidine test compound (final concentration 1 µM). Incubate at 37°C.
  • At designated time points (0, 5, 10, 20, 30, 45 min), withdraw 15 µL aliquots and quench in 100 µL of ice-cold acetonitrile containing an appropriate internal standard.
  • Vortex, centrifuge (13,000 rpm, 10 min, 4°C), and dilute supernatant with water for LC-MS/MS analysis.
  • Plot remaining parent compound (%) vs. time. Calculate half-life (t₁/₂) and intrinsic clearance (CL_int).

3. Visualizations

Diagram 1: LC-MS Workflow for Azetidine Analytics

workflow SamplePrep Sample Preparation (Protocol 2.1) LC LC Separation (Chiral/Chiral or RP) SamplePrep->LC MS MS Detection (HRMS or MRM) LC->MS DataProc Data Processing (Integration, Calibration) MS->DataProc RegReport Regulatory Reporting (CDS, E-Workbook) DataProc->RegReport

Diagram 2: Metabolic Pathway Hypothesis for an Azetidine Scaffold

metabolism Parent Azetidine Parent Drug CYP3A4 CYP3A4 Catalysis Parent->CYP3A4 Primary M1 Oxidation (M1) Excretion Excretion M1->Excretion UGT UGT1A3 Catalysis M1->UGT M2 Ring-Opened Metabolite M2->Excretion M3 Conjugate (Glucuronide) M3->Excretion CYP3A4->M1 CYP3A4->M2 Potential UGT->M3

4. The Scientist's Toolkit: Essential Research Reagent Solutions

Item Function in Azetidine Analytics
Chiral HPLC Columns (e.g., Chiralpak IA/IB/IC) High-performance chiral stationary phases for critical separation of azetidine enantiomers to determine stereochemical purity.
PFP (Pentafluorophenyl) HPLC Columns Provide unique selectivity for polar, basic compounds like azetidines, often improving retention and peak shape in reversed-phase mode.
LC-MS Grade Solvents & Modifiers (0.1% FA, NH4OAc) Ensure low background noise, consistent ionization efficiency, and reproducible retention times in LC-MS analyses.
Stable Isotope-Labeled Internal Standards (e.g., D3-, C13- Azetidine) Essential for accurate and precise bioanalytical quantification (PK studies) via LC-MS/MS, correcting for matrix effects and recovery.
Human Liver Microsomes (HLM) / S9 Fraction Key in vitro system for assessing metabolic stability (Protocol 2.3) and identifying potential metabolic soft spots on the azetidine core.
NADPH Regenerating System Provides essential cofactors for oxidative Phase I metabolism studies in microsomal incubations.
Certified Reference Standards (API, Impurities, Metabolites) Required for unambiguous peak identification, method validation, and establishing system suitability. Critical for regulatory filing.
Mass Spectrometry Data Analysis Software (e.g., Skyline, XCMS) Enables non-targeted metabolite identification, targeted MRM quantification, and processing of complex HRMS data.

Conclusion

The analysis of azetidine amino acids via LC-MS represents a specialized yet increasingly vital capability in modern drug discovery. This article has synthesized a complete workflow, beginning with the foundational understanding of azetidine chemistry, progressing through method development and troubleshooting, and culminating in rigorous validation. The key takeaway is that successful analysis requires a tailored approach addressing the unique polarity, stability, and fragmentation behavior of the strained azetidine ring. Optimized HILIC or mixed-mode chromatography coupled with carefully tuned ESI-MS parameters is essential. As azetidines continue to gain prominence in next-generation therapeutics—particularly in targeted protein degradation and peptide mimetics—robust and sensitive LC-MS assays will be indispensable for advancing candidates from early discovery through clinical development. Future directions include leveraging ion mobility spectrometry (IMS) for enhanced isomeric separation, applying machine learning for fragmentation prediction, and integrating these analyses into high-throughput screening platforms to accelerate the design-make-test-analyze cycle for this promising compound class.
